8F6U | pdb_00008f6u

Crystal Structure of Nanobody VHH113 Bound to Its Antigen PA14 Cif

• PDB DOI: https://doi.org/10.2210/pdb8F6U/pdb

• Classification: IMMUNE SYSTEM
• Organism(s): Pseudomonas aeruginosa PA14, Vicugna pacos
• Expression System: Escherichia coli, Escherichia coli BL21
• Mutation(s): No


• Deposited: 2022-11-17 Released: 2024-03-13
• Deposition Author(s): Simard, A.R., Taher, N.M., Mishra, A.K., Madden, D.R.
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID), National Institutes of Health/National Institute of Diabetes and Digestive and Kidney Disease (NIH/NIDDK), National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS), Cystic Fibrosis Foundation

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.70 Å
• R-Value Free:
  0.199 (Depositor), 0.199 (DCC)
• R-Value Work:
  0.176 (Depositor), 0.176 (DCC)
• R-Value Observed:
  0.177 (Depositor)

Starting Models: experimental

Literature

Convergent strategies for nanobody-mediated inhibition of an epoxide hydrolase

Simard, A.R., Taher, N.M., Beauchemin, K.S., Mishra, A.K., Hederman, A.P., Hampton, T.H., Vasylieva, N., Morisseau, C., Ackerman, M.E., Madden, D.R.

(2026) J Struct Biol X : 100166

• DOI: https://doi.org/10.1016/j.yjsbx.2026.100166

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Hetero 4-mer - A2B2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 101.01 kDa
• Atom Count: 7,404
• Modeled Residue Count: 836
• Deposited Residue Count: 910
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
CFTR inhibitory factor	A [auth D], C	301	Pseudomonas aeruginosa PA14	Mutation(s): 0  Gene Names: PA2394
UniProt
Find proteins for A0A0M3KL26 (Pseudomonas aeruginosa (strain UCBPP-PA14)) Explore A0A0M3KL26  Go to UniProtKB:  A0A0M3KL26

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Nanobody VHH113	B, D [auth A]	154	Vicugna pacos	Mutation(s): 0

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.70 Å
• R-Value Free:  0.199 (Depositor), 0.199 (DCC)
• R-Value Work:  0.176 (Depositor), 0.176 (DCC)
• R-Value Observed: 0.177 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 115.185	α = 90
b = 185.941	β = 90
c = 106.753	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling
PHASER	phasing
Coot	model building

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2024-03-13
Deposition Author(s): Simard, A.R., Taher, N.M., Mishra, A.K., Madden, D.R.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	R01-AI091699
National Institutes of Health/National Institute of Diabetes and Digestive and Kidney Disease (NIH/NIDDK)	United States	P30-DK117469
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	P20-GM113132
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	T32AI007519
Cystic Fibrosis Foundation	United States	STANTO19R0

Revision History

• Version 1.0: 2024-03-13
  Type: Initial release

• Version 1.1: 2024-11-06
  Changes: Structure summary
• Version 1.2: 2026-10-21
  Changes: Database references
