8A39

Crystal Structure of PaaX from Escherichia coli W


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.241
  • R-Value Work: 0.197
  • R-Value Observed: 0.197

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 2.1 of the entry. See complete history


Literature

Structural characterization of PaaX, the main repressor of the phenylacetate degradation pathway in Escherichia coli W: A novel fold of transcription regulator proteins.

Hernandez-Rocamora, V.M.Molina, R.Alba, A.Carrasco-Lopez, C.Rojas-Altuve, A.Panjikar, S.Medina, A.Uson, I.Alfonso, C.Galan, B.Rivas, G.Hermoso, J.A.Sanz, J.M.

(2024) Int J Biol Macromol 254: 127935-127935

  • DOI: https://doi.org/10.1016/j.ijbiomac.2023.127935
  • Primary Citation of Related Structures:
    8A39

  • PubMed Abstract:

    PaaX is a transcriptional repressor of the phenylacetic acid (PAA) catabolic pathway, a central route for bacterial aerobic degradation of aromatic compounds. Induction of the route is achieved through the release of PaaX from its promoter sequences by the first compound of the pathway, phenylacetyl-coenzyme A (PA-CoA). We report the crystal structure of PaaX from Escherichia coli W. PaaX displays a novel type of fold for transcription regulators, showing a dimeric conformation where the monomers present a three-domain structure: an N-terminal winged helix-turn-helix domain, a dimerization domain similar to the Cas2 protein and a C-terminal domain without structural homologs. The domains are separated by a crevice amenable to harbour a PA-CoA molecule. The biophysical characterization of the protein in solution confirmed several hints predicted from the structure, i.e. its dimeric conformation, a modest importance of cysteines and a high dependence of solubility and thermostability on ionic strength. At a moderately acidic pH, the protein formed a stable folding intermediate with remaining α-helical structure, a disrupted tertiary structure and exposed hydrophobic patches. Our results provide valuable information to understand the stability and mechanism of PaaX and pave the way for further analysis of other regulators with similar structural configurations.


  • Organizational Affiliation

    Instituto de Investigación, Desarrollo e Innovación en Biotecnología Sanitaria de Elche, Universidad Miguel Hernández, Av. Universidad, s/n, E-03202 Elche, Alicante, Spain; Centre for Bacterial Cell Biology, Biosciences Institute, Newcastle University, Newcastle upon Tyne, United Kingdom.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA-binding transcriptional repressor of phenylacetic acid degradation, aryl-CoA responsiveA [auth AP1],
B [auth BP1],
C [auth CP1]
316Escherichia coli WMutation(s): 0
Gene Names: paaX
UniProt
Find proteins for A0A024L404 (Escherichia coli)
Explore A0A024L404
Go to UniProtKB:  A0A024L404
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A024L404
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
SO4 (Subject of Investigation/LOI)
Query on SO4

Download Ideal Coordinates CCD File
G [auth AP1]
H [auth AP1]
I [auth AP1]
L [auth BP1]
M [auth BP1]
G [auth AP1],
H [auth AP1],
I [auth AP1],
L [auth BP1],
M [auth BP1],
P [auth CP1],
Q [auth CP1]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL (Subject of Investigation/LOI)
Query on GOL

Download Ideal Coordinates CCD File
D [auth AP1]
E [auth AP1]
F [auth AP1]
J [auth BP1]
K [auth BP1]
D [auth AP1],
E [auth AP1],
F [auth AP1],
J [auth BP1],
K [auth BP1],
N [auth CP1],
O [auth CP1]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.30 Å
  • R-Value Free: 0.241
  • R-Value Work: 0.197
  • R-Value Observed: 0.197
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 167.883α = 90
b = 106.234β = 108.328
c = 85.867γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
Aimlessdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Spanish Ministry of Science, Innovation, and UniversitiesSpainPID2020-115331GB-I00

Revision History  (Full details and data files)

  • Version 1.0: 2023-07-05
    Type: Initial release
  • Version 1.1: 2023-07-19
    Changes: Data collection, Database references, Derived calculations, Refinement description, Source and taxonomy, Structure summary
  • Version 2.0: 2023-10-18
    Type: Coordinate replacement
    Reason: Sequence discrepancy
    Changes: Advisory, Atomic model, Author supporting evidence, Data collection, Database references, Derived calculations, Polymer sequence, Refinement description, Source and taxonomy, Structure summary
  • Version 2.1: 2024-01-17
    Changes: Database references
