8ZWK | pdb_00008zwk

Polyadenylic acid bound alpha-synuclein fibril Polymorph 2

PDB DOI: https://doi.org/10.2210/pdb8ZWK/pdb
NAKB: 8ZWK
EM Map EMD-60530: EMDB EMDataResource

Classification: PROTEIN FIBRIL
Organism(s): Homo sapiens
Expression System: Escherichia coli, Homo sapiens
Mutation(s): No

Deposited: 2024-06-13 Released: 2024-07-03
Deposition Author(s): Tao, Y.Q., Liu, C., Li, D.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.40 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

wwPDB Validation 3D Report Full Report

Validation slider image for 8ZWK

This is version 1.0 of the entry. See complete history.

Literature

Polyadenylic acid bound alpha-synuclein fibril Polymorph 2

Tao, Y.Q., Liu, C., Li, D.

To be published.

Macromolecule Content

Total Structure Weight: 88.74 kDa
Atom Count: 2,760
Modeled Residue Count: 384
Deposited Residue Count: 846
Unique protein chains: 1
Unique nucleic acid chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Alpha-synuclein	A B [auth D] C [auth E] E [auth B] F [auth C] A, B [auth D], C [auth E], E [auth B], F [auth C], G [auth F]	140	Homo sapiens	Mutation(s): 0 Gene Names: SNCA, NACP, PARK1
UniProt & NIH Common Fund Data Resources
Find proteins for P37840 (Homo sapiens) Explore P37840 Go to UniProtKB: P37840
PHAROS: P37840 GTEx: ENSG00000145335
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P37840
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence

Molecule	Chains	Length	Organism	Image
Entity ID: 2
RNA (5'-R(PAPAP*A)-3')	D [auth Q], H [auth G]	3	Homo sapiens
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.40 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-07-03

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2024-07-03
Type: Initial release
