8ZWD | pdb_00008zwd

Crystal structure of methanol dehydrogenase1 from Bacillus methanolicus


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free:
    0.261 (Depositor), 0.255 (DCC)
  • R-Value Work:
    0.214 (Depositor), 0.212 (DCC)
  • R-Value Observed:
    0.216 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 2.1 of the entry. See complete history


Literature

Structural studies of NAD + -dependent methanol dehydrogenase 1 from Bacillus methanolicus MGA3.

Ma, B.D.Kong, X.D.

(2025) Acta Crystallogr D Struct Biol 81: 646-655

  • DOI: https://doi.org/10.1107/S205979832500909X
  • Primary Citation of Related Structures:
    8ZWD

  • PubMed Abstract:

    Methanol, a sustainable and cost-effective C1 compound, has been considered as a promising substrate for the biosynthesis of fuels and value-added chemicals. Synthetic methylotrophs have been developed by integrating natural methanol-assimilation pathways into non-native microbial hosts, with NAD + -dependent methanol dehydrogenases (MDHs) serving as attractive candidates for methanol oxidation. NAD + -dependent MDH1 from the methylotrophic bacterium Bacillus methanolicus MGA3 (BmMDH1) is one of the extensively studied MDHs. Although structural models of BmMDH1 had been proposed, its crystal structure had not been experimentally determined. In this study, the crystal structure of BmMDH1 is reported at 3.0 Å resolution. BmMDH1 forms a decamer made up of five dimers, stabilized by ionic and hydrogen-bonding interactions. Each monomer exhibits a conserved fold which is typical of the type III alcohol dehydrogenase family, comprising an N-terminal α/β dinucleotide-binding domain and a C-terminal all-α helical domain. Similar to other enzymes in this family, it has an NAD + -binding site formed by a Rossmann fold. As a metalloenzyme, BmMDH1 features a metal ion in its active site, coordinated by three histidine residues (His197, His262 and His276) and one aspartate residue (Asp193). Enzyme-activity assays identified Mn 2+ as the most effective metal ion for supporting in vitro enzymatic activity. These findings provide essential structural insights for the rational engineering of methanol-utilizing biocatalysts, thereby advancing sustainable microbial biomanufacturing.


  • Organizational Affiliation
    • State Key Laboratory of Microbial Metabolism, School of Life Sciences and Biotechnology, and Zhangjiang Institute for Advanced Study, Shanghai Jiao Tong University, Shanghai, People's Republic of China.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
NAD(P)-dependent methanol dehydrogenase390Bacillus methanolicusMutation(s): 0
Gene Names: mdhBMMGA3_17200
EC: 1.1.1.244
UniProt
Find proteins for P31005 (Bacillus methanolicus)
Explore P31005
Go to UniProtKB:  P31005
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP31005
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MN
Query on MN

Download Ideal Coordinates CCD File
K [auth B]
L [auth D]
M [auth H]
N [auth J]
O [auth E]
K [auth B],
L [auth D],
M [auth H],
N [auth J],
O [auth E],
P [auth G],
Q [auth F],
R [auth C],
S [auth A],
T [auth I]
MANGANESE (II) ION
Mn
WAEMQWOKJMHJLA-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.00 Å
  • R-Value Free:  0.261 (Depositor), 0.255 (DCC)
  • R-Value Work:  0.214 (Depositor), 0.212 (DCC)
  • R-Value Observed: 0.216 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 256.022α = 90
b = 83.578β = 90
c = 220.557γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
Aimlessdata scaling
XDSdata reduction
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Ministry of Science and Technology (MoST, China)China2021YFA0911000

Revision History  (Full details and data files)

  • Version 1.0: 2025-06-18
    Type: Initial release
  • Version 2.0: 2025-10-08
    Type: Coordinate replacement
    Reason: Atomic clashes
    Changes: Advisory, Atomic model, Data collection, Derived calculations, Non-polymer description, Refinement description, Structure summary
  • Version 2.1: 2025-11-12
    Changes: Database references
