8ZR1 | pdb_00008zr1

Cocrystallization of engineered streptavidin with A9 oligo DNA

• PDB DOI: https://doi.org/10.2210/pdb8ZR1/pdb

• Classification: UNKNOWN FUNCTION
• Organism(s): Streptomyces avidinii
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2024-06-03 Released: 2025-06-04
• Deposition Author(s): Minamihata, K., Adachi, M.
• Funding Organization(s): Other government

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.60 Å
• R-Value Free:
  0.281 (Depositor), 0.286 (DCC)
• R-Value Work:
  0.198 (Depositor), 0.201 (DCC)
• R-Value Observed:
  0.202 (Depositor)

Starting Model: experimental

Literature

Dual-functional co-crystal of streptavidin and ssDNA: electrostatic assembly with positively charged peptide tags.

Nagatani, A., Minamihata, K., Adachi, M., Wakabayashi, R., Goto, M., Kamiya, N.

(2025) RSC Adv 15: 6817-6822

• PubMed: 40035016
• DOI: https://doi.org/10.1039/d4ra08326a
• Primary Citation of Related Structures:
  8ZR1, 8ZR2


• PubMed Abstract:


  We have achieved a novel co-crystal in which the dual functions of the protein and single-stranded DNA are maintained by introducing a charged peptide tag at the C-terminus of the protein. The functionalities allowed the co-crystals to be modified with high selectivity. Additionally, we have confirmed that energy transfer occurs between the two molecules modified within the co-crystal. Therefore, this co-crystal has the potential as a novel biomaterial applicable to biosensors.

---

Organizational Affiliation:
• Department of Applied Chemistry, Graduate School of Engineering, Kyushu University 744 Motooka Fukuoka 819-0395 Japan.
Institute for Quantum Life Science, National Institutes for Quantum Science and Technology 4-9-1 Anagawa, Inage Chiba 263-8555 Japan.
Department of Quantum Life Science, Graduate School of Science, Chiba University Chiba 263-8522 Japan.
Division of Biotechnology, Center for Future Chemistry, Kyushu University 744 Motooka Fukuoka 819-0395 Japan.

Biological Assembly 1

Global Symmetry: Dihedral - D2  (Explore in 3D)
Global Stoichiometry: Homo 4-mer - A4

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 56.75 kDa
• Atom Count: 3,784
• Modeled Residue Count: 488
• Deposited Residue Count: 528
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Streptavidin	A, B, C, D	132	Streptomyces avidinii	Mutation(s): 0
UniProt
Find proteins for P22629 (Streptomyces avidinii) Explore P22629  Go to UniProtKB:  P22629

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.60 Å
• R-Value Free:  0.281 (Depositor), 0.286 (DCC)
• R-Value Work:  0.198 (Depositor), 0.201 (DCC)
• R-Value Observed: 0.202 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 46.084	α = 90.65
b = 58.006	β = 107.54
c = 57.791	γ = 98.84

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data scaling
HKL-2000	data reduction
PHENIX	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-06-04
Deposition Author(s): Minamihata, K., Adachi, M.

---

Funding Organization	Location	Grant Number
Other government		--

Revision History

• Version 1.0: 2025-06-04
  Type: Initial release
