8ZEI | pdb_00008zei

Crystal structure of human cytosolic beta-alanyl lysine dipeptidase with crystal soaked in beta-alanyl histidine

PDB DOI: https://doi.org/10.2210/pdb8ZEI/pdb

Classification: HYDROLASE
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2024-05-06 Released: 2025-05-14
Deposition Author(s): Chandravanshi, K., Kumar, A., Makde, R.D.
Funding Organization(s): Department of Science & Technology (DST, India)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free:
0.219 (Depositor), 0.219 (DCC)
R-Value Work:
0.203 (Depositor), 0.203 (DCC)
R-Value Observed:
0.203 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of human cytosolic beta-alanyl lysine dipeptidase with crystal soaked in beta-alanyl histidine

Chandravanshi, K., Kumar, A., Makde, R.D.

To be published.

Macromolecule Content

Total Structure Weight: 50.3 kDa
Atom Count: 3,155
Modeled Residue Count: 401
Deposited Residue Count: 454
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Xaa-Arg dipeptidase	A	454	Homo sapiens	Mutation(s): 0 Gene Names: PM20D2, ACY1L2 EC: 3.4.13.4
UniProt & NIH Common Fund Data Resources
Find proteins for Q8IYS1 (Homo sapiens) Explore Q8IYS1 Go to UniProtKB: Q8IYS1
PHAROS: Q8IYS1 GTEx: ENSG00000146281
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q8IYS1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
HIS (Subject of Investigation/LOI) Query on HIS Download Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	HISTIDINE C₆ H₁₀ N₃ O₂ HNDVDQJCIGZPNO-YFKPBYRVSA-O		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
TRS (Subject of Investigation/LOI) Query on TRS Download Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL C₄ H₁₂ N O₃ LENZDBCJOHFCAS-UHFFFAOYSA-O		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]
ZN (Subject of Investigation/LOI) Query on ZN Download Ideal Coordinates CCD File SDF format, chain B [auth A] SDF format, chain C [auth A] MOL2 format, chain B [auth A] MOL2 format, chain C [auth A] mmCIF format, chain B [auth A] mmCIF format, chain C [auth A]	B [auth A], C [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A]
ACY (Subject of Investigation/LOI) Query on ACY Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A]	F [auth A], G [auth A]	ACETIC ACID C₂ H₄ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain G [auth A] Interactions & Density Focus chain F [auth A] Focus chain G [auth A]
NA (Subject of Investigation/LOI) Query on NA Download Ideal Coordinates CCD File SDF format, chain H [auth A] MOL2 format, chain H [auth A] mmCIF format, chain H [auth A]	H [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Interactions & Density Focus chain H [auth A]
