8Z4T | pdb_00008z4t

MERS-CoV S ectodomain trimer in complex with receptor DPP4-750E

PDB DOI: https://doi.org/10.2210/pdb8Z4T/pdb
EM Map EMD-39769: EMDB EMDataResource

Classification: VIRAL PROTEIN
Organism(s): Betacoronavirus England 1, Homo sapiens
Expression System: Trichoplusia ni
Mutation(s): Yes

Deposited: 2024-04-17 Released: 2025-10-22
Deposition Author(s): Wang, X., Wang, Z.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.93 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

MERS-CoV S ectodomain trimer in complex with receptor DPP4-750E

Wang, X., Wang, Z.

To be published.

Macromolecule Content

Total Structure Weight: 565.81 kDa
Atom Count: 36,433
Modeled Residue Count: 4,687
Deposited Residue Count: 5,074
Unique protein chains: 2

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Spike glycoprotein	A, B, C	1,206	Betacoronavirus England 1	Mutation(s): 0 Gene Names: S, 3
UniProt
Find proteins for K9N5Q8 (Middle East respiratory syndrome-related coronavirus (isolate United Kingdom/H123990006/2012)) Explore K9N5Q8 Go to UniProtKB: K9N5Q8
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	K9N5Q8
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Dipeptidyl peptidase 4 soluble form	D, E [auth I]	728	Homo sapiens	Mutation(s): 1 Gene Names: DPP4, ADCP2, CD26 EC: 3.4.14.5
UniProt & NIH Common Fund Data Resources
Find proteins for P27487 (Homo sapiens) Explore P27487 Go to UniProtKB: P27487
PHAROS: P27487 GTEx: ENSG00000197635
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P27487
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.93 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2025-10-22

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2025-10-22
Type: Initial release
