8XY8 | pdb_00008xy8

a beta-lactamase - AmpC

PDB DOI: https://doi.org/10.2210/pdb8XY8/pdb

Classification: HYDROLASE
Organism(s): Paraburkholderia xenovorans
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-01-19 Released: 2025-01-22
Deposition Author(s): Ma, W.Z., Song, W.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.39 Å
R-Value Free:
0.255 (Depositor), 0.256 (DCC)
R-Value Work:
0.211 (Depositor), 0.217 (DCC)
R-Value Observed:
0.214 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8XY8

This is version 1.0 of the entry. See complete history.

Literature

Mechanism-Guided Protein Engineering of Paraburkholderia xenovorans Lactamase for the Green Synthesis of 2-(2-oxopyrrolidin-1-yl)-butanoic acid

Ma, W.Z., Song, W.

To be published.

Macromolecule Content

Total Structure Weight: 41.83 kDa
Atom Count: 2,761
Modeled Residue Count: 360
Deposited Residue Count: 391
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta-lactamase	A	391	Paraburkholderia xenovorans	Mutation(s): 0 Gene Names: Bxe_B1593 EC: 3.5.2.6
UniProt
Find proteins for Q13NG8 (Paraburkholderia xenovorans (strain LB400)) Explore Q13NG8 Go to UniProtKB: Q13NG8
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q13NG8
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.39 Å
R-Value Free: 0.255 (Depositor), 0.256 (DCC)
R-Value Work: 0.211 (Depositor), 0.217 (DCC)
R-Value Observed: 0.214 (Depositor)

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 84.94	α = 90
b = 84.94	β = 90
c = 120.6	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-01-22

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2025-01-22
Type: Initial release
