8X23 | pdb_00008x23

The Crystal Structure of MAPK13 from Biortus.

• PDB DOI: https://doi.org/10.2210/pdb8X23/pdb

• Classification: TRANSFERASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2023-11-09 Released: 2023-12-27
• Deposition Author(s): Wang, F., Cheng, W., Yuan, Z., Lin, D., Pan, W.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.50 Å
• R-Value Free:
  0.171 (Depositor), 0.170 (DCC)
• R-Value Work:
  0.124 (Depositor), 0.120 (DCC)

Starting Model: experimental

Literature

The Crystal Structure of MAPK13 from Biortus.

Wang, F., Cheng, W., Lv, Z., Lin, D., Pan, W.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 40.97 kDa
• Atom Count: 3,351
• Modeled Residue Count: 345
• Deposited Residue Count: 352
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitogen-activated protein kinase 13	A	352	Homo sapiens	Mutation(s): 0  Gene Names: MAPK13 EC: 2.7.11.24
UniProt & NIH Common Fund Data Resources
Find proteins for O15264 (Homo sapiens) Explore O15264  Go to UniProtKB:  O15264
PHAROS:  O15264 GTEx:  ENSG00000156711

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL	B [auth A], C [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
EDO	D [auth A], E [auth A], F [auth A]	1,2-ETHANEDIOL C2 H6 O2 LYCAIKOWRPUZTN-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.50 Å
• R-Value Free:  0.171 (Depositor), 0.170 (DCC)
• R-Value Work:  0.124 (Depositor), 0.120 (DCC)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 61.402	α = 90
b = 69.113	β = 90
c = 92.83	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2023-12-27
Deposition Author(s): Wang, F., Cheng, W., Yuan, Z., Lin, D., Pan, W.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2023-12-27
  Type: Initial release
