8W40 | pdb_00008w40

Crystal structure of a computationally designed metalloprotein containing the metal-chelating, fluorogenic, non-canonical amino acid 3-(8-hydroxyquinolin-3-yl)-L-alanine: zinc-bound form

PDB DOI: https://doi.org/10.2210/pdb8W40/pdb

Classification: FLUORESCENT PROTEIN, METAL BINDING PROTEIN
Organism(s): Saccharolobus solfataricus
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-02-22 Released: 2025-02-26
Deposition Author(s): Kelly, P.I., Henderson, J.H., Mills, J.H.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.45 Å
R-Value Free:
0.164 (Depositor), 0.163 (DCC)
R-Value Work:
0.130 (Depositor), 0.135 (DCC)
R-Value Observed:
0.131 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8W40

This is version 1.0 of the entry. See complete history.

Literature

Computational design of a fluorogenic metalloprotein containing the non-canonical amino acid 3-(8-hydroxyquinolin-3-yl)-L-alanine

Kelly, P.I., Henderson, J.N., Mills, J.H.

To be published.

Macromolecule Content

Total Structure Weight: 30.25 kDa
Atom Count: 2,377
Modeled Residue Count: 247
Deposited Residue Count: 258
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Hydroxyquinonline fluorescent protein	A	258	Saccharolobus solfataricus	Mutation(s): 0 EC: 4.1.1.48
UniProt
Find proteins for Q06121 (Saccharolobus solfataricus (strain ATCC 35092 / DSM 1617 / JCM 11322 / P2)) Explore Q06121 Go to UniProtKB: Q06121
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q06121
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] SDF format, chain B [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] MOL2 format, chain B [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A] mmCIF format, chain B [auth A]	B [auth A], C [auth A], D [auth A], E [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A]
ZN Query on ZN Download:Ideal Coordinates CCD File SDF format, chain F [auth A] MOL2 format, chain F [auth A] mmCIF format, chain F [auth A]	F [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Interactions & Density Focus chain F [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
HQA Query on HQA	A	L-PEPTIDE LINKING	C₁₂ H₁₂ N₂ O₃		ALA

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.45 Å
R-Value Free: 0.164 (Depositor), 0.163 (DCC)
R-Value Work: 0.130 (Depositor), 0.135 (DCC)
R-Value Observed: 0.131 (Depositor)

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 62.593	α = 90
b = 62.593	β = 90
c = 121.416	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
XDS	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-02-26

Deposition Author(s):

Henderson, J.H.

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	GM136996-04

Revision History (Full details and data files)

Version 1.0: 2025-02-26
Type: Initial release
