8UOY | pdb_00008uoy

Major interface of Streptococcal surface enolase dimer from AP53 group A streptococcus bound to a lipid vesicle

PDB DOI: https://doi.org/10.2210/pdb8UOY/pdb
EM Map EMD-42441: EMDB EMDataResource

Classification: LYASE
Organism(s): Streptococcus pyogenes
Expression System: Escherichia coli 'BL21-Gold(DE3)pLysS AG
Mutation(s): No

Deposited: 2023-10-20 Released: 2023-12-27
Deposition Author(s): Tjia-Fleck, S., Readnour, B.M., Castellino, F.J.
Funding Organization(s): National Institutes of Health/National Heart, Lung, and Blood Institute (NIH/NHLBI)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.40 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 8UOY

This is version 1.0 of the entry. See complete history.

Literature

Streptococcus surface alpha enolase exposed dimers were found to be the active form on lipid surface that binds to human plasminogen

Tjia-Fleck, S., Readnour, B.M., Castellino, F.J.

To be published.

Macromolecule Content

Total Structure Weight: 95.09 kDa
Atom Count: 6,644
Modeled Residue Count: 872
Deposited Residue Count: 872
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Enolase	A [auth B], B [auth C]	436	Streptococcus pyogenes	Mutation(s): 0 Gene Names: eno, E0F66_01300, E0F67_02490, FGO82_08975, SAMEA1711581_01820, SAMEA864267_00487 EC: 4.2.1.11
UniProt
Find proteins for P69949 (Streptococcus pyogenes serotype M1) Explore P69949 Go to UniProtKB: P69949
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P69949
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.40 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	UCSF ChimeraX

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-12-27

Deposition Author(s):

Castellino, F.J.

Funding Organization	Location	Grant Number
National Institutes of Health/National Heart, Lung, and Blood Institute (NIH/NHLBI)	United States	HL013423

Revision History (Full details and data files)

Version 1.0: 2023-12-27
Type: Initial release
