8U00 | pdb_00008u00

Crystal structure of metallo-beta-lactamase superfamily protein from Caulobacter vibrioides

PDB DOI: https://doi.org/10.2210/pdb8U00/pdb

Classification: HYDROLASE
Organism(s): Caulobacter vibrioides CB15
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2023-08-28 Released: 2023-09-27
Deposition Author(s): Kim, Y., Maltseva, N., Endres, M., Joachimiak, A., Center for Structural Biology of Infectious Diseases (CSBID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free:
0.225 (Depositor), 0.226 (DCC)
R-Value Work:
0.189 (Depositor), 0.189 (DCC)
R-Value Observed:
0.190 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 8U00

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of metallo-beta-lactamase superfamily protein from Caulobacter vibrioides

Kim, Y., Maltseva, N., Endres, M., Joachimiak, A.

To be published.

Macromolecule Content

Total Structure Weight: 59.21 kDa
Atom Count: 3,928
Modeled Residue Count: 484
Deposited Residue Count: 542
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Metallo-beta-lactamase superfamily protein	A, B	271	Caulobacter vibrioides CB15	Mutation(s): 0 Gene Names: CC_2139
UniProt
Find proteins for Q9A6F5 (Caulobacter vibrioides (strain ATCC 19089 / CIP 103742 / CB 15)) Explore Q9A6F5 Go to UniProtKB: Q9A6F5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9A6F5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 6 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain J [auth A] MOL2 format, chain J [auth A] mmCIF format, chain J [auth A]	J [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain J [auth A] Interactions & Density Focus chain J [auth A]
ZN (Subject of Investigation/LOI) Query on ZN Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain F [auth A] SDF format, chain M [auth B] SDF format, chain N [auth B] SDF format, chain O [auth B] SDF format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain F [auth A] MOL2 format, chain M [auth B] MOL2 format, chain N [auth B] MOL2 format, chain O [auth B] MOL2 format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain F [auth A] mmCIF format, chain M [auth B] mmCIF format, chain N [auth B] mmCIF format, chain O [auth B] mmCIF format, chain E [auth A]	D [auth A] E [auth A] F [auth A] M [auth B] N [auth B] D [auth A], E [auth A], F [auth A], M [auth B], N [auth B], O [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain M [auth B] Focus chain N [auth B] Focus chain O [auth B]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain L [auth B] MOL2 format, chain C [auth A] MOL2 format, chain L [auth B] mmCIF format, chain C [auth A] mmCIF format, chain L [auth B]	C [auth A], L [auth B]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain L [auth B] Interactions & Density Focus chain C [auth A] Focus chain L [auth B]
NI Query on NI Download:Ideal Coordinates CCD File SDF format, chain K [auth A] SDF format, chain S [auth B] MOL2 format, chain K [auth A] MOL2 format, chain S [auth B] mmCIF format, chain K [auth A] mmCIF format, chain S [auth B]	K [auth A], S [auth B]	NICKEL (II) ION Ni VEQPNABPJHWNSG-UHFFFAOYSA-N		Interactions Focus chain K [auth A] Focus chain S [auth B] Interactions & Density Focus chain K [auth A] Focus chain S [auth B]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain Q [auth B] SDF format, chain R [auth B] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain Q [auth B] mmCIF format, chain R [auth B]	H [auth A], I [auth A], Q [auth B], R [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain H [auth A] Focus chain I [auth A] Focus chain Q [auth B] Focus chain R [auth B] Interactions & Density Focus chain H [auth A] Focus chain I [auth A] Focus chain Q [auth B] Focus chain R [auth B]
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain P [auth B] MOL2 format, chain G [auth A] MOL2 format, chain P [auth B] mmCIF format, chain G [auth A] mmCIF format, chain P [auth B]	G [auth A], P [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain P [auth B] Interactions & Density Focus chain G [auth A] Focus chain P [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.85 Å
R-Value Free: 0.225 (Depositor), 0.226 (DCC)
R-Value Work: 0.189 (Depositor), 0.189 (DCC)
R-Value Observed: 0.190 (Depositor)

Space Group: P 4₂

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 85.341	α = 90
b = 85.341	β = 90
c = 78.844	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
HKL-3000	phasing
MLPHARE	phasing
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-09-27

Deposition Author(s):

Center for Structural Biology of Infectious Diseases (CSBID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	--

Revision History (Full details and data files)

Version 1.0: 2023-09-27
Type: Initial release
