8TQX

Crystal structure of the Zika virus stem-loop A (SLA) bottom stem

  • Classification: RNA
  • Organism(s): Zika virus
  • Mutation(s): No

  • Deposited: 2023-08-08 Released: 2024-03-06
  • Deposition Author(s): Tipo, J., Gottipati, K., Choi, K.H.
  • Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.09 Å
  • R-Value Free: 0.278
  • R-Value Work: 0.249
  • R-Value Observed: 0.253

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

High-resolution RNA tertiary structures in Zika virus stem-loop A for the development of inhibitory small molecules.

Tipo, J.Gottipati, K.Choi, K.H.

(2024) RNA

  • DOI: https://doi.org/10.1261/rna.079796.123
  • Primary Citation of Related Structures:
    8TQX, 8TSV

  • PubMed Abstract:

    Flaviviruses such as Zika (ZIKV) and dengue virus (DENV) are positive-sense RNA viruses belonging to Flaviviridae. The flavivirus genome contains a 5' end stem-loop promoter sequence known as stem-loop A (SLA) that is recognized by the flavivirus polymerase NS5 during viral RNA synthesis and 5' guanosine cap methylation. The crystal structures of ZIKV and DENV SLAs show a well-defined fold, consisting of a bottom stem, side loop, and top stem-loop, providing unique interaction sites for small-molecule inhibitors to disrupt the promoter function. To facilitate identification of small molecule binding sites in flavivirus SLA, we determined high-resolution structures of bottom and top stems of ZIKV SLA, which contain a single U- or G-bulge, respectively. Both bulge nucleotides exhibit multiple orientations, from folded back on the adjacent nucleotide to flipped out of the helix, and are stabilized by stacking or base triple interactions. These structures suggest that even a single unpaired nucleotide can provide flexibility to RNA structures and its conformation is mainly determined by the stabilizing chemical environment. To facilitate discovery of small molecule inhibitors that interfere with the functions of ZIKV SLA, we screened and identified compounds that bind to the bottom and top stems of ZIKV SLA.


  • Organizational Affiliation

    The University of Texas Medical Branch, Galveston, TX, USA.


Macromolecules

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChains LengthOrganismImage
Zika virus stem-loop A (SLA) bottom stemA,
B [auth D]
19Zika virus
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.09 Å
  • R-Value Free: 0.278
  • R-Value Work: 0.249
  • R-Value Observed: 0.253
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 28.322α = 90
b = 41.947β = 90
c = 97.659γ = 90
Software Package:
Software NamePurpose
Blu-Icedata collection
ELVESdata processing
HKL-2000data reduction
HKL-2000data scaling
PHENIXmodel building
PHENIXrefinement
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesR01AI 187856

Revision History  (Full details and data files)

  • Version 1.0: 2024-03-06
    Type: Initial release
