8SPG | pdb_00008spg

Crystal structure of N-terminally truncated Escherichia coli RapA in complex with MgADP

• PDB DOI: https://doi.org/10.2210/pdb8SPG/pdb

• Classification: TRANSCRIPTION
• Organism(s): Escherichia coli
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2023-05-03 Released: 2024-07-03
• Deposition Author(s): Shaw, G.X., Ji, X.
• Funding Organization(s): National Institutes of Health/National Cancer Institute (NIH/NCI)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.10 Å
• R-Value Free:
  0.236 (Depositor), 0.237 (DCC)
• R-Value Work:
  0.198 (Depositor), 0.198 (DCC)
• R-Value Observed:
  0.199 (Depositor)

Starting Model: experimental

Literature

Crystal structure of N-terminally truncated Escherichia coli RapA in complex with MgADP

Shaw, G.X., Ji, X.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 99.43 kDa
• Atom Count: 7,399
• Modeled Residue Count: 852
• Deposited Residue Count: 867
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
RNA polymerase-associated protein RapA	A	867	Escherichia coli	Mutation(s): 0  Gene Names: rapA, hepA, yabA, b0059, JW0058 EC: 3.6.4
UniProt
Find proteins for P60240 (Escherichia coli (strain K12)) Explore P60240  Go to UniProtKB:  P60240

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ADP (Subject of Investigation/LOI)	B [auth A]	ADENOSINE-5'-DIPHOSPHATE C10 H15 N5 O10 P2 XTWYTFMLZFPYCI-KQYNXXCUSA-N
CL	D [auth A], E [auth A], F [auth A], G [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M
MG (Subject of Investigation/LOI)	C [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.10 Å
• R-Value Free:  0.236 (Depositor), 0.237 (DCC)
• R-Value Work:  0.198 (Depositor), 0.198 (DCC)
• R-Value Observed: 0.199 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 65.567	α = 90
b = 82.099	β = 90
c = 188.546	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
SCALEPACK	data scaling
DENZO	data reduction
PHASER	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2024-07-03
Deposition Author(s): Shaw, G.X., Ji, X.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)	United States	Intramural Research Program

Revision History

• Version 1.0: 2024-07-03
  Type: Initial release
