8SH6 | pdb_00008sh6

Crystal structure of SARS-CoV-2 NSP3 macrodomain Asn40Asp mutant (P43 crystal form)

PDB DOI: https://doi.org/10.2210/pdb8SH6/pdb

Classification: VIRAL PROTEIN
Organism(s): Severe acute respiratory syndrome coronavirus 2
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2023-04-13 Released: 2024-05-01
Deposition Author(s): Correy, G.J., Fraser, J.S.
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 0.90 Å
R-Value Free:
0.126 (Depositor), 0.120 (DCC)
R-Value Work:
0.112 (Depositor), 0.110 (DCC)
R-Value Observed:
0.112 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of SARS-CoV-2 NSP3 macrodomain Asn40Asp mutant (P43 crystal form)

Correy, G.J., Fraser, J.S.

To be published.

Macromolecule Content

Total Structure Weight: 36.36 kDa
Atom Count: 3,444
Modeled Residue Count: 338
Deposited Residue Count: 338
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Papain-like protease nsp3	A, B	169	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 1 Gene Names: rep, 1a-1b EC: 3.4.19.12 (PDB Primary Data), 3.4.22 (PDB Primary Data)
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTD1 Go to UniProtKB: P0DTD1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P0DTD1
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 0.90 Å
R-Value Free: 0.126 (Depositor), 0.120 (DCC)
R-Value Work: 0.112 (Depositor), 0.110 (DCC)
R-Value Observed: 0.112 (Depositor)

Space Group: P 4₃

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 88.72	α = 90
b = 88.72	β = 90
c = 39.735	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
PHENIX	refinement
XDS	data scaling
Coot	model building
PHASER	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2024-05-01

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	U19AI171110

Revision History (Full details and data files)

Version 1.0: 2024-05-01
Type: Initial release
