8RMB | pdb_00008rmb

Erk2 MAP kinase (R65S+T188D) double mutant

• PDB DOI: https://doi.org/10.2210/pdb8RMB/pdb

• Classification: TRANSFERASE
• Organism(s): Rattus norvegicus
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2024-01-05 Released: 2025-01-15
• Deposition Author(s): Livnah, O., Gutman, D.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.55 Å
• R-Value Free:
  0.230 (Depositor), 0.236 (DCC)
• R-Value Work:
  0.199 (Depositor), 0.207 (DCC)
• R-Value Observed:
  0.200 (Depositor)

Starting Model: experimental

Literature

Erk2 MAP kinase (R65S+T188D) double mutant

Livnah, O., Guman, D.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 42.17 kDa
• Atom Count: 2,999
• Modeled Residue Count: 347
• Deposited Residue Count: 365
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitogen-activated protein kinase 1	A	365	Rattus norvegicus	Mutation(s): 2  Gene Names: Mapk1, Erk2, Mapk, Prkm1 EC: 2.7.11.24
UniProt
Find proteins for P63086 (Rattus norvegicus) Explore P63086  Go to UniProtKB:  P63086

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.55 Å
• R-Value Free:  0.230 (Depositor), 0.236 (DCC)
• R-Value Work:  0.199 (Depositor), 0.207 (DCC)
• R-Value Observed: 0.200 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 48.531	α = 90
b = 69.371	β = 109.04
c = 59.899	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
XDS	data scaling
MOLREP	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-01-15
Deposition Author(s): Livnah, O., Gutman, D.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2025-01-15
  Type: Initial release
