8RCN | pdb_00008rcn

CryoEM structure of mTORC1 with a paediatric kidney cancer-associated 1455-EWED-1458 duplication in mTOR, Focused region of mTOR and RAPTOR on one protomer copy.

• PDB DOI: https://doi.org/10.2210/pdb8RCN/pdb
• EM Map EMD-19056: EMDB EMDataResource

• Classification: SIGNALING PROTEIN
• Organism(s): Homo sapiens
• Expression System: Homo sapiens, Escherichia coli
• Mutation(s): No


• Deposited: 2023-12-06 Released: 2024-09-11
• Deposition Author(s): Anandapadamanaban, M., Hay, I.M., Perisic, O., Williams, R.L.
• Funding Organization(s): Cancer Research UK, Medical Research Council (MRC, United Kingdom), European Molecular Biology Organization (EMBO)

---

Experimental Data Snapshot

• Method: ELECTRON MICROSCOPY
• Resolution: 3.10 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Literature

CryoEM structure of mTORC1 with a paediatric kidney cancer-associated 1455-EWED-1458 duplication in mTOR, Focused region of mTOR and RAPTOR on one protomer copy.

Anandapadamanaban, M., Hay, I.M., Perisic, O., Williams, R.L.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Hetero 3-mer - A1B1C1

Biological assembly 1 assigned by authors and generated by (software)

Biological Assembly Evidence: electron microscopy

Macromolecule Content

• Total Structure Weight: 451.61 kDa
• Atom Count: 14,999
• Modeled Residue Count: 1,854
• Deposited Residue Count: 4,002
• Unique protein chains: 3

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Serine/threonine-protein kinase mTOR	A [auth B]	2,549	Homo sapiens	Mutation(s): 0  Gene Names: MTOR, FRAP, FRAP1, FRAP2, RAFT1, RAPT1 EC: 2.7.11.1 (PDB Primary Data), 2.7.10.2 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for P42345 (Homo sapiens) Explore P42345  Go to UniProtKB:  P42345
PHAROS:  P42345 GTEx:  ENSG00000198793

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Regulatory-associated protein of mTOR	B [auth Y]	1,335	Homo sapiens	Mutation(s): 0  Gene Names: RPTOR, KIAA1303, RAPTOR
UniProt & NIH Common Fund Data Resources
Find proteins for Q8N122 (Homo sapiens) Explore Q8N122  Go to UniProtKB:  Q8N122
PHAROS:  Q8N122 GTEx:  ENSG00000141564

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Eukaryotic translation initiation factor 4E-binding protein 1	C [auth X]	118	Homo sapiens	Mutation(s): 0  Gene Names: EIF4EBP1
UniProt & NIH Common Fund Data Resources
Find proteins for Q13541 (Homo sapiens) Explore Q13541  Go to UniProtKB:  Q13541
PHAROS:  Q13541 GTEx:  ENSG00000187840

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ANP (Subject of Investigation/LOI)	D [auth B]	PHOSPHOAMINOPHOSPHONIC ACID-ADENYLATE ESTER C10 H17 N6 O12 P3 PVKSNHVPLWYQGJ-KQYNXXCUSA-N
MG (Subject of Investigation/LOI)	E [auth B], F [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: ELECTRON MICROSCOPY
• Resolution: 3.10 Å
• Aggregation State: PARTICLE
• Reconstruction Method: SINGLE PARTICLE

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2024-09-11
Deposition Author(s): Anandapadamanaban, M., Hay, I.M., Perisic, O., Williams, R.L.

---

Funding Organization	Location	Grant Number
Cancer Research UK	United Kingdom	DRCPGM 100014
Medical Research Council (MRC, United Kingdom)	United Kingdom	MC_U105184308
European Molecular Biology Organization (EMBO)	European Union	EMBO ALTF 603-2019

Revision History

• Version 1.0: 2024-09-11
  Type: Initial release
