8QLW | pdb_00008qlw

Purpureocillium lilancinum Woronin Body Major protein crystallized in cellulo

PDB DOI: https://doi.org/10.2210/pdb8QLW/pdb

Classification: STRUCTURAL PROTEIN
Organism(s): Purpureocillium lilacinum
Expression System: Trichoplusia ni
Mutation(s): No

Deposited: 2023-09-20 Released: 2024-10-02
Deposition Author(s): Boger, J., Redecke, L.
Funding Organization(s): German Federal Ministry for Education and Research

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.97 Å
R-Value Free:
0.236 (Depositor), 0.238 (DCC)
R-Value Work:
0.200 (Depositor), 0.201 (DCC)
R-Value Observed:
0.204 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8QLW

This is version 1.0 of the entry. See complete history.

Literature

Purpureocillium lilancinum Woronin Body Major protein crystallized in cellulo

Boger, J., Redecke, L.

To be published.

Macromolecule Content

Total Structure Weight: 23.39 kDa
Atom Count: 1,420
Modeled Residue Count: 175
Deposited Residue Count: 208
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Woronin body major protein	A	208	Purpureocillium lilacinum	Mutation(s): 0 Gene Names: PCL_00196
UniProt
Find proteins for A0A2U3E6B3 (Purpureocillium lilacinum) Explore A0A2U3E6B3 Go to UniProtKB: A0A2U3E6B3
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A2U3E6B3
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.97 Å
R-Value Free: 0.236 (Depositor), 0.238 (DCC)
R-Value Work: 0.200 (Depositor), 0.201 (DCC)
R-Value Observed: 0.204 (Depositor)

Space Group: P 6₅ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 57.1	α = 90
b = 57.1	β = 90
c = 200.34	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
PHENIX	refinement
CrystFEL	data reduction
CrystFEL	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-10-02

Deposition Author(s):

Funding Organization	Location	Grant Number
German Federal Ministry for Education and Research	Germany	05K18FLA

Revision History (Full details and data files)

Version 1.0: 2024-10-02
Type: Initial release
