8QLU | pdb_00008qlu

Aspergillus fumigatus Woronin Body Major protein crystallized in cellulo

PDB DOI: https://doi.org/10.2210/pdb8QLU/pdb

Classification: STRUCTURAL PROTEIN
Organism(s): Aspergillus fumigatus
Expression System: Trichoplusia ni
Mutation(s): No

Deposited: 2023-09-20 Released: 2024-10-02
Deposition Author(s): Boger, J., Redecke, L.
Funding Organization(s): German Federal Ministry for Education and Research

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.02 Å
R-Value Free:
0.229 (Depositor), 0.235 (DCC)
R-Value Work:
0.217 (Depositor), 0.217 (DCC)
R-Value Observed:
0.218 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8QLU

This is version 1.0 of the entry. See complete history.

Literature

HEX-1 protein structures in comparison

Boger, J., Redecke, L.

To be published.

Macromolecule Content

Total Structure Weight: 24.81 kDa
Atom Count: 1,114
Modeled Residue Count: 137
Deposited Residue Count: 218
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Woronin body major protein hexA	A	218	Aspergillus fumigatus	Mutation(s): 0 Gene Names: hexA
UniProt
Find proteins for Q4WUL0 (Aspergillus fumigatus (strain ATCC MYA-4609 / CBS 101355 / FGSC A1100 / Af293)) Explore Q4WUL0 Go to UniProtKB: Q4WUL0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q4WUL0
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.02 Å
R-Value Free: 0.229 (Depositor), 0.235 (DCC)
R-Value Work: 0.217 (Depositor), 0.217 (DCC)
R-Value Observed: 0.218 (Depositor)

Space Group: P 6₅ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 58.36	α = 90
b = 58.36	β = 90
c = 190.05	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
PHENIX	refinement
CrystFEL	data reduction
CrystFEL	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2024-10-02

Deposition Author(s):

Funding Organization	Location	Grant Number
German Federal Ministry for Education and Research	Germany	05K18FLA

Revision History (Full details and data files)

Version 1.0: 2024-10-02
Type: Initial release
