8PGG | pdb_00008pgg

Crystal structure of the metallo-beta-lactamase VIM1 with 2954

• PDB DOI: https://doi.org/10.2210/pdb8PGG/pdb

• Classification: ANTIMICROBIAL PROTEIN
• Organism(s): Pseudomonas aeruginosa
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2023-06-18 Released: 2024-07-10
• Deposition Author(s): Calvopina, K., Brem, J., Farley, A.J.M., Allen, M.D., Schofield, C.J.
• Funding Organization(s): Wellcome Trust

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.20 Å
• R-Value Free:
  0.152 (Depositor), 0.122 (DCC)
• R-Value Work:
  0.121 (Depositor)
• R-Value Observed:
  0.122 (Depositor)

Starting Model: experimental

Literature

Crystal structure of the metallo-beta-lactamase VIM1 with 2954

Calvopina, K., Brem, J., Farley, A.J.M., Allen, M.D., Schofield, C.J.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 28.65 kDa
• Atom Count: 2,299
• Modeled Residue Count: 231
• Deposited Residue Count: 266
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta-lactamase VIM-1	A	266	Pseudomonas aeruginosa	Mutation(s): 0  Gene Names: blaVIM, blaVIM-1, CAZ10_38240, CAZ10_38245 EC: 3.5.2.6
UniProt
Find proteins for Q9XAY4 (Pseudomonas aeruginosa) Explore Q9XAY4  Go to UniProtKB:  Q9XAY4

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
YU3 (Subject of Investigation/LOI)	D [auth A]	3-[3-fluoranyl-4-(methylsulfonylmethyl)phenyl]-7-[(1~{S})-1-(2-oxidanylidene-1~{H}-pyridin-3-yl)ethyl]-1~{H}-indole-2-carboxylic acid C24 H21 F N2 O5 S KPFIGINTOHZVNI-ZDUSSCGKSA-N
ZN	B [auth A], C [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.20 Å
• R-Value Free:  0.152 (Depositor), 0.122 (DCC)
• R-Value Work:  0.121 (Depositor)
• R-Value Observed: 0.122 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 38.67	α = 90
b = 67.15	β = 90.29
c = 39.82	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
xia2	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2024-07-10
Deposition Author(s): Calvopina, K., Brem, J., Farley, A.J.M., Allen, M.D., Schofield, C.J.

---

Funding Organization	Location	Grant Number
Wellcome Trust	United Kingdom	099141/Z/12/Z

Revision History

• Version 1.0: 2024-07-10
  Type: Initial release
