8OFG | pdb_00008ofg

Streptococcus pneumoniae CdaA in complex with c-di-amp

PDB DOI: https://doi.org/10.2210/pdb8OFG/pdb

Classification: TRANSFERASE
Organism(s): Streptococcus pneumoniae R6
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2023-03-15 Released: 2023-06-21
Deposition Author(s): Garbers, T.B., Neumann, P., Ficner, R.
Funding Organization(s): German Research Foundation (DFG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free:
0.252 (Depositor), 0.253 (DCC)
R-Value Work:
0.224 (Depositor), 0.224 (DCC)
R-Value Observed:
0.225 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 8OFG

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Streptococcus pneumoniae CdaA in complex with c-di-amp

Garbers, T.B., Neumann, P., Ficner, R.

To be published.

Macromolecule Content

Total Structure Weight: 41.57 kDa
Atom Count: 2,462
Modeled Residue Count: 309
Deposited Residue Count: 370
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Diadenylate cyclase	A, B	181	Streptococcus pneumoniae R6	Mutation(s): 0 Gene Names: dacA EC: 2.7.7.85
UniProt
Find proteins for Q8DP14 (Streptococcus pneumoniae (strain ATCC BAA-255 / R6)) Explore Q8DP14 Go to UniProtKB: Q8DP14
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8DP14
Sequence Annotations Expand
Reference Sequence

Find similar proteins by: Sequence | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
GLU-ARG-LEU-LEU-GLY-GLY-TRP-LYS	C	8	Streptococcus pneumoniae R6	Mutation(s): 0

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
AMP (Subject of Investigation/LOI) Query on AMP Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	ADENOSINE MONOPHOSPHATE C₁₀ H₁₄ N₅ O₇ P UDMBCSSLTHHNCD-KQYNXXCUSA-N		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
MG (Subject of Investigation/LOI) Query on MG Download:Ideal Coordinates CCD File SDF format, chain E [auth A] MOL2 format, chain E [auth A] mmCIF format, chain E [auth A]	E [auth A]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Interactions & Density Focus chain E [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free: 0.252 (Depositor), 0.253 (DCC)
R-Value Work: 0.224 (Depositor), 0.224 (DCC)
R-Value Observed: 0.225 (Depositor)

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 86.57	α = 90
b = 86.57	β = 90
c = 110.62	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XSCALE	data scaling
XDS	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-06-21

Deposition Author(s):

Funding Organization	Location	Grant Number
German Research Foundation (DFG)	Germany	SPP 1879

Revision History (Full details and data files)

Version 1.0: 2023-06-21
Type: Initial release
Version 1.1: 2024-06-19
Changes: Data collection
