8J56

Crystal structure of the FlhDC complex from Cupriavidus necator


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.50 Å
  • R-Value Free: 0.261
  • R-Value Work: 0.220
  • R-Value Observed: 0.222

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Hexameric structure of the flagellar master regulator FlhDC from Cupriavidus necator and its interaction with flagellar promoter DNA.

Cho, S.Y.Oh, H.B.Yoon, S.I.

(2023) Biochem Biophys Res Commun 672: 97-102

  • DOI: https://doi.org/10.1016/j.bbrc.2023.06.033
  • Primary Citation of Related Structures:
    8J56

  • PubMed Abstract:

    Bacterial flagella are assembled with ∼30 different proteins in a defined order via diverse regulatory systems. In gram-negative bacteria from the Gammaproteobacteria and Betaproteobacteria classes, the transcription of flagellar genes is strictly controlled by the master regulator FlhDC. In Gammaproteobacteria species, the FlhDC complex has been shown to activate flagellar expression by directly interacting with the promoter region in flagellar genes. To obtain the DNA-binding mechanism of FlhDC and determine the conserved and distinct structural features of Betaproteobacteria and Gammaproteobacteria FlhDCs that are necessary for their functions, we determined the crystal structure of Betaproteobacteria Cupriavidus necator FlhDC (cnFlhDC) and biochemically analyzed its DNA-binding capacity. cnFlhDC specifically recognized the promoter DNA of the class II flagellar genes flgB and flhB. cnFlhDC adopts a ring-like heterohexameric structure (cnFlhD 4 C 2 ) and harbors two Zn-Cys clusters, as observed for Gammaproteobacteria Escherichia coli FlhDC (ecFlhDC). The cnFlhDC structure exhibits positively charged surfaces across two FlhDC subunits as a putative DNA-binding site. Noticeably, the positive patch of cnFlhDC is continuous, in contrast to the separated patches of ecFlhDC. Moreover, the ternary intersection of cnFlhD 4 C 2 behind the Zn-Cys cluster forms a unique protruding neutral structure, which is replaced with a charged cavity in the ecFlhDC structure.


  • Organizational Affiliation

    Division of Biomedical Convergence, College of Biomedical Science, Kangwon National University, Chuncheon, 24341, Republic of Korea.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Flagellar transcriptional regulator FlhD
A, B, D, E
111Cupriavidus necatorMutation(s): 0
Gene Names: flhDFHX61_004144
UniProt
Find proteins for A0A7W4VD94 (Cupriavidus alkaliphilus)
Explore A0A7W4VD94
Go to UniProtKB:  A0A7W4VD94
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A7W4VD94
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Flagellar transcriptional regulator FlhC
C, F
201Cupriavidus necatorMutation(s): 0
Gene Names: flhC
UniProt
Find proteins for A0A7T4G0G8 (Cupriavidus necator)
Explore A0A7T4G0G8
Go to UniProtKB:  A0A7T4G0G8
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A7T4G0G8
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.50 Å
  • R-Value Free: 0.261
  • R-Value Work: 0.220
  • R-Value Observed: 0.222
  • Space Group: P 32 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 124.533α = 90
b = 124.533β = 90
c = 173.853γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Research Foundation (NRF, Korea)Korea, Republic OfRS-2023-00208153

Revision History  (Full details and data files)

  • Version 1.0: 2024-02-28
    Type: Initial release
