8H3Z | pdb_00008h3z

Crystal structure of the effector-binding domain of the LysR-type trasncription factor NtcB from Anabaena PCC 7120

PDB DOI: https://doi.org/10.2210/pdb8H3Z/pdb

Classification: TRANSCRIPTION/DNA
Organism(s): Anabaena
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2022-10-09 Released: 2023-10-04
Deposition Author(s): Han, S.J., Jiang, Y.L., Zhou, C.Z.
Funding Organization(s): Chinese Academy of Sciences, National Natural Science Foundation of China (NSFC), Ministry of Science and Technology (MoST, China)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.35 Å
R-Value Free:
0.243 (Depositor)
R-Value Work:
0.204 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Literature

DNA looping mediates cooperative transcription activation.

Han, S.J., Jiang, Y.L., You, L.L., Shen, L.Q., Wu, X., Yang, F., Cui, N., Kong, W.W., Sun, H., Zhou, K., Meng, H.C., Chen, Z.P., Chen, Y., Zhang, Y., Zhou, C.Z.

(2024) Nat Struct Mol Biol 31: 293-299

PubMed: 38177666 Search on PubMed Search on PubMed Central
DOI: https://doi.org/10.1038/s41594-023-01149-7
Primary Citation Related Structures:
8H3V, 8H3Z, 8H40

PubMed Abstract:
Transcription factors respond to multilevel stimuli and co-occupy promoter regions of target genes to activate RNA polymerase (RNAP) in a cooperative manner. To decipher the molecular mechanism, here we report two cryo-electron microscopy structures of Anabaena transcription activation complexes (TACs): NtcA-TAC composed of RNAP holoenzyme, promoter and a global activator NtcA, and NtcA-NtcB-TAC comprising an extra context-specific regulator, NtcB. Structural analysis showed that NtcA binding makes the promoter DNA bend by ∼50°, which facilitates RNAP to contact NtcB at the distal upstream NtcB box. The sequential binding of NtcA and NtcB induces looping back of promoter DNA towards RNAP, enabling the assembly of a fully activated TAC bound with two activators. Together with biochemical assays, we propose a 'DNA looping' mechanism of cooperative transcription activation in bacteria.

Organizational Affiliation

School of Life Sciences and Biomedical Sciences and Health Laboratory of Anhui Province, Division of Life Sciences and Medicine, University of Science & Technology of China, Hefei, China.

Macromolecule Content

Total Structure Weight: 54.82 kDa
Atom Count: 3,310
Modeled Residue Count: 401
Deposited Residue Count: 456
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
NtcB	A, B	228	Anabaena	Mutation(s): 0 Gene Names: ntcB
UniProt
Find proteins for Q9L3R4 (Nostoc sp. (strain PCC 7120 / SAG 25.82 / UTEX 2576)) Explore Q9L3R4 Go to UniProtKB: Q9L3R4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9L3R4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
IOD (Subject of Investigation/LOI) Query on IOD Download:Ideal Coordinates CCD File SDF format, chain Z [auth B] SDF format, chain Y [auth B] SDF format, chain X [auth B] SDF format, chain W [auth B] SDF format, chain V [auth B] SDF format, chain U [auth B] SDF format, chain T [auth B] SDF format, chain S [auth B] SDF format, chain R [auth B] SDF format, chain Q [auth B] SDF format, chain P [auth B] SDF format, chain O [auth B] SDF format, chain N [auth A] SDF format, chain M [auth A] SDF format, chain L [auth A] SDF format, chain K [auth A] SDF format, chain J [auth A] SDF format, chain I [auth A] SDF format, chain H [auth A] SDF format, chain G [auth A] SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] SDF format, chain AA [auth B] MOL2 format, chain Z [auth B] MOL2 format, chain Y [auth B] MOL2 format, chain X [auth B] MOL2 format, chain W [auth B] MOL2 format, chain V [auth B] MOL2 format, chain U [auth B] MOL2 format, chain T [auth B] MOL2 format, chain S [auth B] MOL2 format, chain R [auth B] MOL2 format, chain Q [auth B] MOL2 format, chain P [auth B] MOL2 format, chain O [auth B] MOL2 format, chain N [auth A] MOL2 format, chain M [auth A] MOL2 format, chain L [auth A] MOL2 format, chain K [auth A] MOL2 format, chain J [auth A] MOL2 format, chain I [auth A] MOL2 format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] MOL2 format, chain AA [auth B] mmCIF format, chain Z [auth B] mmCIF format, chain Y [auth B] mmCIF format, chain X [auth B] mmCIF format, chain W [auth B] mmCIF format, chain V [auth B] mmCIF format, chain U [auth B] mmCIF format, chain T [auth B] mmCIF format, chain S [auth B] mmCIF format, chain R [auth B] mmCIF format, chain Q [auth B] mmCIF format, chain P [auth B] mmCIF format, chain O [auth B] mmCIF format, chain N [auth A] mmCIF format, chain M [auth A] mmCIF format, chain L [auth A] mmCIF format, chain K [auth A] mmCIF format, chain J [auth A] mmCIF format, chain I [auth A] mmCIF format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A] mmCIF format, chain AA [auth B]	AA [auth B] C [auth A] D [auth A] E [auth A] F [auth A] AA [auth B], C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], N [auth A], O [auth B], P [auth B], Q [auth B], R [auth B], S [auth B], T [auth B], U [auth B], V [auth B], W [auth B], X [auth B], Y [auth B], Z [auth B]	IODIDE ION I XMBWDFGMSWQBCA-UHFFFAOYSA-M		Interactions Focus chain AA [auth B] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B] Interactions & Density Focus chain AA [auth B] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth B] Focus chain P [auth B] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.35 Å
R-Value Free: 0.243 (Depositor)
R-Value Work: 0.204 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 59.697	α = 90
b = 69.41	β = 90
c = 114.31	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
SCALA	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-10-04

Deposition Author(s):

Han, S.J.

Jiang, Y.L.

Zhou, C.Z.

Funding Organization	Location	Grant Number
Chinese Academy of Sciences	China	XDB37020301, XDA24020302
National Natural Science Foundation of China (NSFC)	China	32171198
Ministry of Science and Technology (MoST, China)	China	2018YFA090070
