8GWJ | pdb_00008gwj

SARS CoV-2 Mpro 1-302 C145A in complex with peptide 7

• PDB DOI: https://doi.org/10.2210/pdb8GWJ/pdb

• Classification: HYDROLASE
• Organism(s): Severe acute respiratory syndrome coronavirus 2
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2022-09-17 Released: 2023-09-20
• Deposition Author(s): Liu, M., Huang, H.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.90 Å
• R-Value Free:
  0.271 (Depositor), 0.270 (DCC)
• R-Value Work:
  0.211 (Depositor), 0.220 (DCC)
• R-Value Observed:
  0.214 (Depositor)

Literature

SARS CoV-2 Mpro 1-302 C145A in complex with peptide 7

Liu, M., Huang, H.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Hetero 4-mer - A2B2 Pseudo Symmetry: Asymmetric - C1
Pseudo Stoichiometry: Hetero 4-mer - A2B1C1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 68.56 kDa
• Atom Count: 4,594
• Modeled Residue Count: 601
• Deposited Residue Count: 620
• Unique protein chains: 2

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Replicase polyprotein 1ab	A, B	302	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0  Gene Names: rep, 1a-1b EC: 3.4.22.69
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTD1  Go to UniProtKB:  P0DTD1

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
VAL-LYS-LEU-GLN-ALA-VAL-PHE-ARG	C, D	8	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.90 Å
• R-Value Free:  0.271 (Depositor), 0.270 (DCC)
• R-Value Work:  0.211 (Depositor), 0.220 (DCC)
• R-Value Observed: 0.214 (Depositor)

Space Group: P 3₁ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 66.892	α = 90
b = 66.892	β = 90
c = 240.659	γ = 120

Software Package:

Software Name	Purpose
REFMAC	refinement
SCALA	data scaling
PDB_EXTRACT	data extraction
CrysalisPro	data reduction
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2023-09-20
Deposition Author(s): Liu, M., Huang, H.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2023-09-20
  Type: Initial release
