8GDJ | pdb_00008gdj

Crystal Structure of HIV-1 LM/HT CLADE A/E CRF01 GP120 Core in Complex with TFH-II-128

PDB DOI: https://doi.org/10.2210/pdb8GDJ/pdb

Classification: VIRAL PROTEIN/INHIBITOR
Organism(s): Human immunodeficiency virus 1
Expression System: Homo sapiens
Mutation(s): Yes

Deposited: 2023-03-06 Released: 2024-03-20
Deposition Author(s): Nguyen, D.N., Tolbert, W.D., Pazgier, M.
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.42 Å
R-Value Free:
0.286 (Depositor), 0.280 (DCC)
R-Value Work:
0.228 (Depositor), 0.230 (DCC)
R-Value Observed:
0.231 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal Structure of HIV-1 LM/HT CLADE A/E CRF01 GP120 Core in Complex with TFH-II-128

Nguyen, D.N., Tolbert, W.D., Pazgier, M.

To be published.

Macromolecule Content

Total Structure Weight: 42.77 kDa
Atom Count: 2,918
Modeled Residue Count: 341
Deposited Residue Count: 355
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
HIV-1 LM/HT Clade A/E CRF01 gp120 core	A	355	Human immunodeficiency virus 1	Mutation(s): 7 Gene Names: HIV-1 Env
UniProt
Find proteins for A0A0M3KKW9 (Human immunodeficiency virus type 1) Explore A0A0M3KKW9 Go to UniProtKB: A0A0M3KKW9
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A0M3KKW9
Glycosylation
Glycosylation Sites: 12	Glycosylation Focus chain A
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
Z6F (Subject of Investigation/LOI) Query on Z6F Download Ideal Coordinates CCD File SDF format, chain N [auth A] MOL2 format, chain N [auth A] mmCIF format, chain N [auth A]	N [auth A]	(3S,5R)-N-(4-chloro-3-fluorophenyl)-5-(hydroxymethyl)-1-(4-methylpiperazine-1-carbonyl)piperidine-3-carboxamide C₁₉ H₂₆ Cl F N₄ O₃ YJQIDERPUXKPOK-KGLIPLIRSA-N		Interactions Focus chain N [auth A] Interactions & Density Focus chain N [auth A]
EPE Query on EPE Download Ideal Coordinates CCD File SDF format, chain O [auth A] MOL2 format, chain O [auth A] mmCIF format, chain O [auth A]	O [auth A]	4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID C₈ H₁₈ N₂ O₄ S JKMHFZQWWAIEOD-UHFFFAOYSA-N		Interactions Focus chain O [auth A] Interactions & Density Focus chain O [auth A]
NAG Query on NAG Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain H [auth A] SDF format, chain B [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain H [auth A] MOL2 format, chain B [auth A] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A] mmCIF format, chain H [auth A] mmCIF format, chain B [auth A]	B [auth A] C [auth A] D [auth A] E [auth A] F [auth A] B [auth A], C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], J [auth A], K [auth A], L [auth A], M [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Interactions & Density Focus chain B [auth A] Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A]
