8FA5 | pdb_00008fa5

Crystal structure of Xanthomonas campestris GH35 beta-galactosidase

PDB DOI: https://doi.org/10.2210/pdb8FA5/pdb

Classification: HYDROLASE
Organism(s): Xanthomonas campestris pv. campestris
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2022-11-25 Released: 2023-11-29
Deposition Author(s): Godoy, A.S., Polikarpov, I.
Funding Organization(s): Sao Paulo Research Foundation (FAPESP)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free:
0.203 (Depositor), 0.178 (DCC)
R-Value Work:
0.170 (Depositor)
R-Value Observed:
0.171 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8FA5

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of Xanthomonas campestris GanA beta-galactosidase

Godoy, A.S., Polikarpov, I.

To be published.

Macromolecule Content

Total Structure Weight: 132.63 kDa
Atom Count: 10,606
Modeled Residue Count: 1,170
Deposited Residue Count: 1,182
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta-galactosidase	A [auth B], B [auth A]	591	Xanthomonas campestris pv. campestris	Mutation(s): 0 Gene Names: bga EC: 3.2.1.23
UniProt
Find proteins for Q8P6S0 (Xanthomonas campestris pv. campestris (strain ATCC 33913 / DSM 3586 / NCPPB 528 / LMG 568 / P 25)) Explore Q8P6S0 Go to UniProtKB: Q8P6S0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8P6S0
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain Q [auth A] SDF format, chain P [auth A] SDF format, chain O [auth A] SDF format, chain N [auth A] SDF format, chain M [auth B] SDF format, chain L [auth B] SDF format, chain K [auth B] SDF format, chain J [auth B] SDF format, chain I [auth B] SDF format, chain H [auth B] SDF format, chain G [auth B] SDF format, chain F [auth B] SDF format, chain E [auth B] SDF format, chain D [auth B] SDF format, chain C [auth B] MOL2 format, chain Q [auth A] MOL2 format, chain P [auth A] MOL2 format, chain O [auth A] MOL2 format, chain N [auth A] MOL2 format, chain M [auth B] MOL2 format, chain L [auth B] MOL2 format, chain K [auth B] MOL2 format, chain J [auth B] MOL2 format, chain I [auth B] MOL2 format, chain H [auth B] MOL2 format, chain G [auth B] MOL2 format, chain F [auth B] MOL2 format, chain E [auth B] MOL2 format, chain D [auth B] MOL2 format, chain C [auth B] mmCIF format, chain Q [auth A] mmCIF format, chain P [auth A] mmCIF format, chain O [auth A] mmCIF format, chain N [auth A] mmCIF format, chain M [auth B] mmCIF format, chain L [auth B] mmCIF format, chain K [auth B] mmCIF format, chain J [auth B] mmCIF format, chain I [auth B] mmCIF format, chain H [auth B] mmCIF format, chain G [auth B] mmCIF format, chain F [auth B] mmCIF format, chain E [auth B] mmCIF format, chain D [auth B] mmCIF format, chain C [auth B]	C [auth B] D [auth B] E [auth B] F [auth B] G [auth B] C [auth B], D [auth B], E [auth B], F [auth B], G [auth B], H [auth B], I [auth B], J [auth B], K [auth B], L [auth B], M [auth B], N [auth A], O [auth A], P [auth A], Q [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth B] Focus chain D [auth B] Focus chain E [auth B] Focus chain F [auth B] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Interactions & Density Focus chain C [auth B] Focus chain D [auth B] Focus chain E [auth B] Focus chain F [auth B] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth B] Focus chain M [auth B] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.70 Å
R-Value Free: 0.203 (Depositor), 0.178 (DCC)
R-Value Work: 0.170 (Depositor)
R-Value Observed: 0.171 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 80.865	α = 90
b = 84.768	β = 96.61
c = 99.811	γ = 90

Software Package:

Software Name	Purpose
Aimless	data scaling
XDS	data reduction
PHENIX	refinement
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-11-29

Deposition Author(s):

Funding Organization	Location	Grant Number
Sao Paulo Research Foundation (FAPESP)	Brazil	2011/05712-3

Revision History (Full details and data files)

Version 1.0: 2023-11-29
Type: Initial release
