8ETN

The X-ray Crystal Structure of Tri-Ketone Dioxygenase from Rice


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.16 Å
  • R-Value Free: 0.318
  • R-Value Work: 0.274
  • R-Value Observed: 0.276

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Structural and functional characterization of triketone dioxygenase from Oryza Sativa.

Duff, S.M.G.Zhang, M.Zinnel, F.Rydel, T.Taylor, C.M.Chen, D.Tilton, G.Mamanella, P.Duda, D.Wang, Y.Xiang, B.Karunanandaa, B.Varagona, R.Chittoor, J.Qi, Q.Hall, E.Garvey, G.Zeng, J.Zhang, J.Li, X.White, T.Jerga, A.Haas, J.

(2023) Biochim Biophys Acta Gen Subj 1868: 130504-130504

  • DOI: https://doi.org/10.1016/j.bbagen.2023.130504
  • Primary Citation of Related Structures:
    8ETN

  • PubMed Abstract:

    The transgenic expression of rice triketone dioxygenase (TDO; also known as HIS1) can provide protection from triketone herbicides to susceptible dicot crops such as soybean. Triketones are phytotoxic inhibitors of plant hydroxyphenylpyruvate dioxygenases (HPPD). The TDO gene codes for an iron/2-oxoglutarate-dependent oxidoreductase. We obtained an X-ray crystal structure of TDO using SeMet-SAD phasing to 3.16 Å resolution. The structure reveals that TDO possesses a fold like that of Arabidopsis thaliana 2-oxoglutarate‑iron-dependent oxygenase anthocyanidin synthase (ANS). Unlike ANS, this TDO structure lacks bound metals or cofactors, and we propose this is because the disordered flexible loop over the active site is sterically constrained from folding properly in the crystal lattice. A combination of mass spectrometry, nuclear magnetic resonance, and enzyme activity studies indicate that rice TDO oxidizes mesotrione in a series of steps; first producing 5-hydroxy-mesotrione and then oxy-mesotrione. Evidence suggests that 5-hydroxy-mesotrione is a much weaker inhibitor of HPPD than mesotrione, and oxy-mesotrione has virtually no inhibitory activity. Of the close homologues which have been tested, only corn and rice TDO have enzymatic activity and the ability to protect plants from mesotrione. Correlating sequence and structure has identified four amino acids necessary for TDO activity. Introducing these four amino acids imparts activity to a mesotrione-inactive TDO-like protein from sorghum, which may expand triketone herbicide resistance in new crop species.


  • Organizational Affiliation

    Bayer Crop Science, Chesterfield, MO, USA. Electronic address: stephen.duff@bayer.com.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Tri-Ketone DioxygenaseA,
B [auth D],
C,
D [auth B]
360Oryza sativaMutation(s): 0
UniProt
Find proteins for Q6ES21 (Oryza sativa subsp. japonica)
Explore Q6ES21
Go to UniProtKB:  Q6ES21
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ6ES21
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
A,
B [auth D],
C,
D [auth B]
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.16 Å
  • R-Value Free: 0.318
  • R-Value Work: 0.274
  • R-Value Observed: 0.276
  • Space Group: P 41
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 73.565α = 90
b = 73.565β = 90
c = 259.828γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PHENIXrefinement
HKL-2000data reduction
HKL-2000data scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2023-12-06
    Type: Initial release
  • Version 1.1: 2023-12-27
    Changes: Database references
