8E7S

III2IV2 respiratory supercomplex from Saccharomyces cerevisiae with 4 bound UQ6


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.20 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Structural insights into cardiolipin replacement by phosphatidylglycerol in a cardiolipin-lacking yeast respiratory supercomplex.

Hryc, C.F.Mallampalli, V.K.P.S.Bovshik, E.I.Azinas, S.Fan, G.Serysheva, I.I.Sparagna, G.C.Baker, M.L.Mileykovskaya, E.Dowhan, W.

(2023) Nat Commun 14: 2783-2783

  • DOI: https://doi.org/10.1038/s41467-023-38441-5
  • Primary Citation of Related Structures:
    8E7S, 8EC0

  • PubMed Abstract:
  • Cardiolipin is a hallmark phospholipid of mitochondrial membranes. Despite established significance of cardiolipin in supporting respiratory supercomplex organization, a mechanistic understanding of this lipid-protein interaction is still lacking. To address the essential role of cardiolipin in supercomplex organization, we report cryo-EM structures of a wild type supercomplex (IV 1 III 2 IV 1 ) and a supercomplex (III 2 IV 1 ) isolated from a cardiolipin-lacking Saccharomyces cerevisiae mutant at 3 ...

    Cardiolipin is a hallmark phospholipid of mitochondrial membranes. Despite established significance of cardiolipin in supporting respiratory supercomplex organization, a mechanistic understanding of this lipid-protein interaction is still lacking. To address the essential role of cardiolipin in supercomplex organization, we report cryo-EM structures of a wild type supercomplex (IV 1 III 2 IV 1 ) and a supercomplex (III 2 IV 1 ) isolated from a cardiolipin-lacking Saccharomyces cerevisiae mutant at 3.2-Å and 3.3-Å resolution, respectively, and demonstrate that phosphatidylglycerol in III 2 IV 1 occupies similar positions as cardiolipin in IV 1 III 2 IV 1 . Lipid-protein interactions within these complexes differ, which conceivably underlies the reduced level of IV 1 III 2 IV 1 and high levels of III 2 IV 1 and free III 2 and IV in mutant mitochondria. Here we show that anionic phospholipids interact with positive amino acids and appear to nucleate a phospholipid domain at the interface between the individual complexes, which dampen charge repulsion and further stabilize interaction, respectively, between individual complexes.


    Organizational Affiliation

    Department of Biochemistry and Molecular Biology, Center for Membrane Biology, McGovern Medical School at the University of Texas Health Science Center, Houston, Texas, USA. william.dowhan@uth.tmc.edu.



Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome b-c1 complex subunit 1, mitochondrialA,
W [auth a]
457Saccharomyces cerevisiaeMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P07256 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P07256
Go to UniProtKB:  P07256
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP07256
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome b-c1 complex subunit 2, mitochondrialB,
X [auth b]
368Saccharomyces cerevisiaeMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P07257 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P07257
Go to UniProtKB:  P07257
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP07257
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome b-c1 complex subunit Rieske, mitochondrialC,
Y [auth c]
215Saccharomyces cerevisiaeMutation(s): 0
EC: 7.1.1.8
Membrane Entity: Yes
UniProt
Find proteins for P08067 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P08067
Go to UniProtKB:  P08067
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP08067
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome b-c1 complex subunit 10, mitochondrialD,
Z [auth d]
77Saccharomyces cerevisiaeMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P37299 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P37299
Go to UniProtKB:  P37299
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP37299
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome b-c1 complex subunit 9, mitochondrialAA [auth e],
E
66Saccharomyces cerevisiaeMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P22289 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P22289
Go to UniProtKB:  P22289
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP22289
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome b-c1 complex subunit 7, mitochondrialBA [auth f],
F
127Saccharomyces cerevisiaeMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P00128 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P00128
Go to UniProtKB:  P00128
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00128
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome b-c1 complex subunit 6, mitochondrialCA [auth g],
G
147Saccharomyces cerevisiaeMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P00127 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P00127
Go to UniProtKB:  P00127
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00127
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome b-c1 complex subunit 8, mitochondrialDA [auth h],
H
94Saccharomyces cerevisiaeMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P08525 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P08525
Go to UniProtKB:  P08525
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP08525
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome bEA [auth j],
I [auth J]
385Saccharomyces cerevisiaeMutation(s): 0
EC: 7.1.1.8
Membrane Entity: Yes
UniProt
Find proteins for P00163 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P00163
Go to UniProtKB:  P00163
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00163
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome c oxidase subunit 1FA [auth k],
J [auth K]
534Saccharomyces cerevisiaeMutation(s): 0
EC: 7.1.1.9
Membrane Entity: Yes
UniProt
Find proteins for P00401 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P00401
Go to UniProtKB:  P00401
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00401
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome c1, heme protein, mitochondrialGA [auth l],
K [auth L]
309Saccharomyces cerevisiaeMutation(s): 0
EC: 7.1.1.8
Membrane Entity: Yes
UniProt
Find proteins for P07143 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P07143
Go to UniProtKB:  P07143
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP07143
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome c oxidase subunit 8, mitochondrialHA [auth m],
L [auth M]
78Saccharomyces cerevisiaeMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P04039 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P04039
Go to UniProtKB:  P04039
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04039
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome c oxidase subunit 7, mitochondrialIA [auth n],
M [auth N]
60Saccharomyces cerevisiaeMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P10174 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P10174
Go to UniProtKB:  P10174
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP10174
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome c oxidase subunit 3JA [auth o],
N [auth O]
269Saccharomyces cerevisiaeMutation(s): 0
EC: 7.1.1.9
Membrane Entity: Yes
UniProt
Find proteins for P00420 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P00420
Go to UniProtKB:  P00420
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00420
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 15
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome c oxidase subunit 2KA [auth p],
O [auth P]
251Saccharomyces cerevisiaeMutation(s): 0
EC: 7.1.1.9
Membrane Entity: Yes
UniProt
Find proteins for P00410 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P00410
Go to UniProtKB:  P00410
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00410
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 16
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome c oxidase subunit 6, mitochondrialLA [auth q],
P [auth Q]
148Saccharomyces cerevisiaeMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P00427 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P00427
Go to UniProtKB:  P00427
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00427
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 17
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome c oxidase subunit 9, mitochondrialMA [auth r],
Q [auth R]
59Saccharomyces cerevisiaeMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P07255 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P07255
Go to UniProtKB:  P07255
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP07255
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 18
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome c oxidase subunit 13, mitochondrialNA [auth s],
R [auth S]
129Saccharomyces cerevisiaeMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P32799 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P32799
Go to UniProtKB:  P32799
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP32799
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 19
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome c oxidase subunit 4, mitochondrialOA [auth t],
S [auth T]
155Saccharomyces cerevisiaeMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P04037 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P04037
Go to UniProtKB:  P04037
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP04037
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 20
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome c oxidase subunit 12, mitochondrialPA [auth u],
T [auth U]
83Saccharomyces cerevisiaeMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q01519 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q01519
Go to UniProtKB:  Q01519
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ01519
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 21
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome c oxidase subunit 26, mitochondrialQA [auth v],
U [auth V]
66Saccharomyces cerevisiaeMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for Q2V2P9 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q2V2P9
Go to UniProtKB:  Q2V2P9
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ2V2P9
Protein Feature View
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 22
MoleculeChainsSequence LengthOrganismDetailsImage
Cytochrome c oxidase subunit 5A, mitochondrialRA [auth w],
V [auth W]
153Saccharomyces cerevisiaeMutation(s): 0
Membrane Entity: Yes
UniProt
Find proteins for P00424 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P00424
Go to UniProtKB:  P00424
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00424
Protein Feature View
Expand
  • Reference Sequence
Small Molecules
Ligands 10 Unique
IDChainsName / Formula / InChI Key2D Diagram3D Interactions
CDL (Subject of Investigation/LOI)
Query on CDL

Download Ideal Coordinates CCD File
BB [auth H],
DC [auth c],
FB [auth J],
HC [auth h],
IC [auth h],
BB [auth H],
DC [auth c],
FB [auth J],
HC [auth h],
IC [auth h],
KC [auth j],
OB [auth K],
RB [auth L],
SC [auth k],
WA [auth C]
CARDIOLIPIN
C81 H156 O17 P2
XVTUQDWPJJBEHJ-KZCWQMDCSA-L
 Ligand Interaction
HEA
Query on HEA

Download Ideal Coordinates CCD File
MB [auth K],
PB [auth K],
TC [auth k],
UC [auth k]
HEME-A
C49 H56 Fe N4 O6
ZGGYGTCPXNDTRV-PRYGPKJJSA-L
 Ligand Interaction
PCF (Subject of Investigation/LOI)
Query on PCF

Download Ideal Coordinates CCD File
CB [auth H],
CD [auth w],
VC [auth k],
XB [auth W],
ZA [auth E],
CB [auth H],
CD [auth w],
VC [auth k],
XB [auth W],
ZA [auth E],
ZB [auth a]
1,2-DIACYL-SN-GLYCERO-3-PHOSHOCHOLINE
C40 H80 N O8 P
KILNVBDSWZSGLL-KXQOOQHDSA-N
 Ligand Interaction
PEF (Subject of Investigation/LOI)
Query on PEF

Download Ideal Coordinates CCD File
AB [auth E],
AC [auth a],
AD [auth w],
BC [auth a],
BD [auth w],
AB [auth E],
AC [auth a],
AD [auth w],
BC [auth a],
BD [auth w],
DB [auth J],
EC [auth c],
FC [auth c],
GC [auth e],
JB [auth J],
JC [auth j],
LB [auth J],
OC [auth j],
QC [auth j],
SA [auth A],
TA [auth A],
UA [auth A],
UB [auth V],
VB [auth W],
WB [auth W],
XA [auth C],
YA [auth C],
YB [auth a],
ZC [auth v]
DI-PALMITOYL-3-SN-PHOSPHATIDYLETHANOLAMINE
C37 H74 N O8 P
SLKDGVPOSSLUAI-PGUFJCEWSA-N
 Ligand Interaction
CN5
Query on CN5

Download Ideal Coordinates CCD File
EB [auth J](5S,11R)-5,8,11-trihydroxy-5,11-dioxido-17-oxo-4,6,10,12,16-pentaoxa-5,11-diphosphaoctadec-1-yl pentadecanoate
C26 H52 O13 P2
UKWPDXFRXMWSMQ-VWLOTQADSA-N
 Ligand Interaction
HEM
Query on HEM

Download Ideal Coordinates CCD File
GB [auth J],
HB [auth J],
LC [auth j],
MC [auth j],
QB [auth L],
GB [auth J],
HB [auth J],
LC [auth j],
MC [auth j],
QB [auth L],
WC [auth l]
PROTOPORPHYRIN IX CONTAINING FE
C34 H32 Fe N4 O4
KABFMIBPWCXCRK-RGGAHWMASA-L
 Ligand Interaction
UQ6 (Subject of Investigation/LOI)
Query on UQ6

Download Ideal Coordinates CCD File
IB [auth J],
KB [auth J],
NC [auth j],
PC [auth j]
5-(3,7,11,15,19,23-HEXAMETHYL-TETRACOSA-2,6,10,14,18,22-HEXAENYL)-2,3-DIMETHOXY-6-METHYL-BENZENE-1,4-DIOL
C39 H60 O4
DYOSCPIQEYRQEO-XQCASOQKSA-N
 Ligand Interaction
FES
Query on FES

Download Ideal Coordinates CCD File
CC [auth c],
VA [auth C]
FE2/S2 (INORGANIC) CLUSTER
Fe2 S2
NIXDOXVAJZFRNF-UHFFFAOYSA-N
 Ligand Interaction
CUA
Query on CUA

Download Ideal Coordinates CCD File
SB [auth P],
TB [auth P],
XC [auth p],
YC [auth p]
DINUCLEAR COPPER ION
Cu2
ALKZAGKDWUSJED-UHFFFAOYSA-N
 Ligand Interaction
CU
Query on CU

Download Ideal Coordinates CCD File
NB [auth K],
RC [auth k]
COPPER (II) ION
Cu
JPVYNHNXODAKFH-UHFFFAOYSA-N
 Ligand Interaction
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.20 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR01GM115969
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesP01GM063210

Revision History  (Full details and data files)

  • Version 1.0: 2023-05-24
    Type: Initial release
