8E67 | pdb_00008e67

ETV6 H396Y variant bound to DNA containing the sequence GGAT

PDB DOI: https://doi.org/10.2210/pdb8E67/pdb
NAKB: 8E67

Classification: DNA BINDING PROTEIN/DNA
Organism(s): synthetic construct, Mus musculus
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2022-08-22 Released: 2023-08-30
Deposition Author(s): Scheu, K., Chan, A.C., Murphy, M.E., McIntosh, L.P.
Funding Organization(s): Canadian Institutes of Health Research (CIHR)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free:
0.267 (Depositor), 0.264 (DCC)
R-Value Work:
0.211 (Depositor)
R-Value Observed:
0.214 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 8E67

This is version 1.1 of the entry. See complete history.

Literature

The functional role of histidine within the ETV6 ETS domain

Scheu, K., Chan, A.C., Murphy, M.E., McIntosh, L.P.

To be published.

Macromolecule Content

Total Structure Weight: 86.06 kDa
Atom Count: 5,655
Modeled Residue Count: 493
Deposited Residue Count: 524
Unique protein chains: 1
Unique nucleic acid chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Transcription factor ETV6	C [auth A], F, I, L	101	Mus musculus	Mutation(s): 1 Gene Names: Etv6
UniProt & NIH Common Fund Data Resources
Find proteins for P97360 (Mus musculus) Explore P97360 Go to UniProtKB: P97360
IMPC: MGI:109336
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P97360
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence

Molecule	Chains	Length	Organism	Image
Entity ID: 1
GGAT-containing 15 bp DNA	A [auth B], D, G, J	15	synthetic construct
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence

Molecule	Chains	Length	Organism	Image
Entity ID: 2
Complementary 15 bp strand	B [auth C], E, H, K	15	synthetic construct
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free: 0.267 (Depositor), 0.264 (DCC)
R-Value Work: 0.211 (Depositor)
R-Value Observed: 0.214 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 63.94	α = 90
b = 74.35	β = 98.02
c = 76.62	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling
PDB_EXTRACT	data extraction
PHENIX	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-08-30

Deposition Author(s):

Funding Organization	Location	Grant Number
Canadian Institutes of Health Research (CIHR)	Canada	--

Revision History (Full details and data files)

Version 1.0: 2023-08-30
Type: Initial release
Version 1.1: 2026-03-04
Changes: Refinement description, Structure summary
