8DHJ

Crystal structure of Clostridioides difficile Protein Tyrosine Phosphatase at pH 7.5

PDB DOI: https://doi.org/10.2210/pdb8DHJ/pdb

Classification: HYDROLASE
Organism(s): Clostridioides difficile 6050
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2022-06-27 Released: 2023-07-05
Deposition Author(s): Lountos, G.T., Tropea, J.E.
Funding Organization(s): National Institutes of Health/National Cancer Institute (NIH/NCI)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.48 Å
R-Value Free: 0.199
R-Value Work: 0.156
R-Value Observed: 0.159

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.1 of the entry. See complete history.

Literature

Crystal structure of Clostridioides difficile Protein Tyrosine Phosphatase at pH 7.5

Lountos, G.T., Tropea, J.E.

To be published.

Macromolecule Content

Total Structure Weight: 58.66 kDa
Atom Count: 4,560
Modelled Residue Count: 473
Deposited Residue Count: 498
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
TYR_PHOSPHATASE_2 domain-containing protein	A, B	249	Clostridioides difficile 6050	Mutation(s): 0
UniProt
Find proteins for Q185E4 (Clostridioides difficile (strain 630)) Explore Q185E4 Go to UniProtKB: Q185E4
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q185E4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EPE (Subject of Investigation/LOI) Query on EPE Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain H [auth B] MOL2 format, chain C [auth A] MOL2 format, chain H [auth B]	C [auth A], H [auth B]	4-(2-HYDROXYETHYL)-1-PIPERAZINE ETHANESULFONIC ACID C₈ H₁₈ N₂ O₄ S JKMHFZQWWAIEOD-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain H [auth B] Interactions & Density Focus chain C [auth A] Focus chain H [auth B]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain I [auth B] SDF format, chain J [auth B] SDF format, chain K [auth B] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain I [auth B] MOL2 format, chain J [auth B] MOL2 format, chain K [auth B]	D [auth A] E [auth A] F [auth A] G [auth A] I [auth B] D [auth A], E [auth A], F [auth A], G [auth A], I [auth B], J [auth B], K [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B]
