8CU1 | pdb_00008cu1

Structure of a K+ selective NaK mutant (NaK2K, Laue diffraction) in the presence of an electric field of ~0.8MV/cm along the crystallographic z axis, 500ns, with eightfold extrapolation of structure factor differences

PDB DOI: https://doi.org/10.2210/pdb8CU1/pdb

Classification: MEMBRANE PROTEIN
Organism(s): Bacillus cereus m1550
Expression System: Escherichia coli
Mutation(s): No
Membrane Protein: Yes PDBTM

Deposited: 2022-05-16 Released: 2023-07-26
Deposition Author(s): Lee, B., White, K.I., Socolich, M.A., Klureza, M.A., Henning, R., Srajer, V., Ranganathan, R., Hekstra, D.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS), National Institutes of Health/Eunice Kennedy Shriver National Institute of Child Health & Human Development (NIH/NICHD), Department of Energy (DOE, United States), Kinship Foundation, New York Community Trust

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.01 Å
R-Value Free:
0.371 (Depositor), 0.293 (DCC)
R-Value Work:
0.334 (Depositor)
R-Value Observed:
0.336 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

Direct visualization of electric field-stimulated ion conduction in a potassium channel

Lee, B., White, K.I., Socolich, M.A., Klureza, M.A., Henning, R., Srajer, V., Ranganathan, R., Hekstra, D.

To be published.

Macromolecule Content

Total Structure Weight: 24.14 kDa
Atom Count: 2,095
Modeled Residue Count: 191
Deposited Residue Count: 192
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Potassium channel protein	A, B	96	Bacillus cereus m1550	Mutation(s): 0 Gene Names: BCB4264_A0706 Membrane Entity: Yes
UniProt
Find proteins for B7HBV5 (Bacillus cereus (strain B4264)) Explore B7HBV5 Go to UniProtKB: B7HBV5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	B7HBV5
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	D Interactions
alpha-D-glucopyranose-(1-4)-alpha-D-glucopyranose	C [auth D]	2		N/A	Interactions Focus chain C [auth D] Interactions & Density Focus chain C [auth D]
Glycosylation Resources
GlyTouCan: G07411ON GlyCosmos: G07411ON

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MPD Query on MPD Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain Q [auth B] SDF format, chain R [auth B] SDF format, chain T [auth B] SDF format, chain U [auth B] SDF format, chain V [auth B] SDF format, chain X [auth B] SDF format, chain Y [auth B] SDF format, chain Z [auth B] SDF format, chain W [auth B] SDF format, chain S [auth B] SDF format, chain I [auth A] SDF format, chain AA [auth B] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] MOL2 format, chain T [auth B] MOL2 format, chain U [auth B] MOL2 format, chain V [auth B] MOL2 format, chain X [auth B] MOL2 format, chain Y [auth B] MOL2 format, chain Z [auth B] MOL2 format, chain W [auth B] MOL2 format, chain S [auth B] MOL2 format, chain I [auth A] MOL2 format, chain AA [auth B] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain Q [auth B] mmCIF format, chain R [auth B] mmCIF format, chain T [auth B] mmCIF format, chain U [auth B] mmCIF format, chain V [auth B] mmCIF format, chain X [auth B] mmCIF format, chain Y [auth B] mmCIF format, chain Z [auth B] mmCIF format, chain W [auth B] mmCIF format, chain S [auth B] mmCIF format, chain I [auth A] mmCIF format, chain AA [auth B]	AA [auth B] D [auth A] E [auth A] F [auth A] G [auth A] AA [auth B], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A], I [auth A], Q [auth B], R [auth B], S [auth B], T [auth B], U [auth B], V [auth B], W [auth B], X [auth B], Y [auth B], Z [auth B]	(4S)-2-METHYL-2,4-PENTANEDIOL C₆ H₁₄ O₂ SVTBMSDMJJWYQN-YFKPBYRVSA-N		Interactions Focus chain AA [auth B] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B] Interactions & Density Focus chain AA [auth B] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth A] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B]
K (Subject of Investigation/LOI) Query on K Download:Ideal Coordinates CCD File SDF format, chain BA [auth B] SDF format, chain DA [auth B] SDF format, chain EA [auth B] SDF format, chain FA [auth B] SDF format, chain GA [auth B] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain O [auth A] SDF format, chain P [auth A] SDF format, chain CA [auth B] MOL2 format, chain BA [auth B] MOL2 format, chain DA [auth B] MOL2 format, chain EA [auth B] MOL2 format, chain FA [auth B] MOL2 format, chain GA [auth B] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] MOL2 format, chain P [auth A] MOL2 format, chain CA [auth B] mmCIF format, chain BA [auth B] mmCIF format, chain DA [auth B] mmCIF format, chain EA [auth B] mmCIF format, chain FA [auth B] mmCIF format, chain GA [auth B] mmCIF format, chain J [auth A] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain M [auth A] mmCIF format, chain N [auth A] mmCIF format, chain O [auth A] mmCIF format, chain P [auth A] mmCIF format, chain CA [auth B]	BA [auth B] CA [auth B] DA [auth B] EA [auth B] FA [auth B] BA [auth B], CA [auth B], DA [auth B], EA [auth B], FA [auth B], GA [auth B], J [auth A], K [auth A], L [auth A], M [auth A], N [auth A], O [auth A], P [auth A]	POTASSIUM ION K NPYPAHLBTDXSSS-UHFFFAOYSA-N		Interactions Focus chain BA [auth B] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain EA [auth B] Focus chain FA [auth B] Focus chain GA [auth B] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Interactions & Density Focus chain BA [auth B] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain EA [auth B] Focus chain FA [auth B] Focus chain GA [auth B] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.01 Å
R-Value Free: 0.371 (Depositor), 0.293 (DCC)
R-Value Work: 0.334 (Depositor)
R-Value Observed: 0.336 (Depositor)

Space Group: I 4

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 68.816	α = 90
b = 68.816	β = 90
c = 90.365	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Precognition	data reduction
Epinorm	data reduction
PHENIX	phasing
Precognition	data scaling

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-07-26

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	RO1GM12345
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	RO1GM141697
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	P41GM118217
National Institutes of Health/Eunice Kennedy Shriver National Institute of Child Health & Human Development (NIH/NICHD)	United States	DP2OD028805
Department of Energy (DOE, United States)	United States	DE-AC02-06CH11357
Department of Energy (DOE, United States)	United States	DE-AC02-76SF00515
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	P41GM103393
Kinship Foundation		SSP-2018-3240
New York Community Trust		338034
