8CNY

Structure of Enterovirus A71 3C protease

PDB DOI: https://doi.org/10.2210/pdb8CNY/pdb

Classification: ANTIVIRAL PROTEIN
Organism(s): Enterovirus
Expression System: Escherichia coli BL21
Mutation(s): No

Deposited: 2023-02-24 Released: 2023-04-05
Deposition Author(s): Lithgo, R.M., Fairhead, M., Koekemoer, L., Aschenbrenner, J.C., Balcomb, B.H., Godoy, A.S., Marples, P.G., Ni, X., Tomlinson, C.W.E., Wild, C., Fearon, D., Walsh, M.A., von Delft, F.
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.51 Å
R-Value Free: 0.210
R-Value Work: 0.179

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Structure of EV D68 3C protease - to be published

Lithgo, R.M., von Delft, F.

To be published.

Macromolecule Content

Total Structure Weight: 21.36 kDa
Atom Count: 1,565
Modelled Residue Count: 182
Deposited Residue Count: 192
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Genome polyprotein	A	192	Enterovirus	Mutation(s): 0
UniProt
Find proteins for B8YLV8 (Human enterovirus 71) Explore B8YLV8 Go to UniProtKB: B8YLV8
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	B8YLV8
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.51 Å
R-Value Free: 0.210
R-Value Work: 0.179
Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 64.9	α = 90
b = 65.73	β = 90
c = 76.27	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
xia2	data reduction
xia2	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2023-04-05

Deposition Author(s):

Aschenbrenner, J.C.

Tomlinson, C.W.E.

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	U19AI171399

Revision History (Full details and data files)

Version 1.0: 2023-04-05
Type: Initial release
