8C3L | pdb_00008c3l

PaaR2 N-terminal domain in complex with nanobody 33

PDB DOI: https://doi.org/10.2210/pdb8C3L/pdb

Classification: DNA BINDING PROTEIN
Organism(s): Escherichia coli O157:H7, Lama glama
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2022-12-26 Released: 2023-03-15
Deposition Author(s): Loris, R., Prolic-Kalinsek, M.
Funding Organization(s): Research Foundation - Flanders (FWO)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.60 Å
R-Value Free:
0.254 (Depositor), 0.260 (DCC)
R-Value Work:
0.219 (Depositor), 0.230 (DCC)
R-Value Observed:
0.220 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.1 of the entry. See complete history.

Literature

PaaR2, the CI equivalent in Escherichia coli O157:H7 cryptic prophage CP-933P

Prolik-Kalinsek, M., Volkov, A., Loris, R.

To be published.

Macromolecule Content

Total Structure Weight: 43.2 kDa
Atom Count: 2,797
Modeled Residue Count: 340
Deposited Residue Count: 366
Unique protein chains: 2

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Phage repressor protein CI	A, C	66	Escherichia coli O157:H7	Mutation(s): 0 Gene Names: ECs_2279
UniProt
Find proteins for Q8XAD6 (Escherichia coli O157:H7) Explore Q8XAD6 Go to UniProtKB: Q8XAD6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q8XAD6
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Nanobody 33	B, D	117	Lama glama	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
IOD Query on IOD Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] SDF format, chain I [auth B] SDF format, chain J [auth B] SDF format, chain K [auth B] SDF format, chain L [auth C] SDF format, chain M [auth C] SDF format, chain N [auth C] SDF format, chain O [auth C] SDF format, chain S [auth D] SDF format, chain T [auth D] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] MOL2 format, chain I [auth B] MOL2 format, chain J [auth B] MOL2 format, chain K [auth B] MOL2 format, chain L [auth C] MOL2 format, chain M [auth C] MOL2 format, chain N [auth C] MOL2 format, chain O [auth C] MOL2 format, chain S [auth D] MOL2 format, chain T [auth D] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A] mmCIF format, chain I [auth B] mmCIF format, chain J [auth B] mmCIF format, chain K [auth B] mmCIF format, chain L [auth C] mmCIF format, chain M [auth C] mmCIF format, chain N [auth C] mmCIF format, chain O [auth C] mmCIF format, chain S [auth D] mmCIF format, chain T [auth D]	E [auth A] F [auth A] G [auth A] H [auth A] I [auth B] E [auth A], F [auth A], G [auth A], H [auth A], I [auth B], J [auth B], K [auth B], L [auth C], M [auth C], N [auth C], O [auth C], S [auth D], T [auth D]	IODIDE ION I XMBWDFGMSWQBCA-UHFFFAOYSA-M		Interactions Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth C] Focus chain M [auth C] Focus chain N [auth C] Focus chain O [auth C] Focus chain S [auth D] Focus chain T [auth D] Interactions & Density Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain K [auth B] Focus chain L [auth C] Focus chain M [auth C] Focus chain N [auth C] Focus chain O [auth C] Focus chain S [auth D] Focus chain T [auth D]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain Q [auth C] SDF format, chain R [auth C] SDF format, chain U [auth D] SDF format, chain P [auth C] MOL2 format, chain Q [auth C] MOL2 format, chain R [auth C] MOL2 format, chain U [auth D] MOL2 format, chain P [auth C] mmCIF format, chain Q [auth C] mmCIF format, chain R [auth C] mmCIF format, chain U [auth D] mmCIF format, chain P [auth C]	P [auth C], Q [auth C], R [auth C], U [auth D]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain P [auth C] Focus chain Q [auth C] Focus chain R [auth C] Focus chain U [auth D] Interactions & Density Focus chain P [auth C] Focus chain Q [auth C] Focus chain R [auth C] Focus chain U [auth D]
