8BHD

N-terminal domain of Plasmodium berghei glutamyl-tRNA synthetase (Tbxo4 derivative crystal structure)


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.17 Å
  • R-Value Free: 0.237
  • R-Value Work: 0.192
  • R-Value Observed: 0.194

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

Solution X-ray scattering highlights discrepancies in Plasmodium multi-aminoacyl-tRNA synthetase complexes.

Jaramillo Ponce, J.R.Theobald-Dietrich, A.Benas, P.Paulus, C.Sauter, C.Frugier, M.

(2023) Protein Sci 32: e4564-e4564

  • DOI: https://doi.org/10.1002/pro.4564
  • Primary Citation of Related Structures:
    8BCQ, 8BHD

  • PubMed Abstract:

    tRip is a tRNA import protein specific to Plasmodium, the causative agent of malaria. In addition to its membrane localization and tRNA trafficking properties, tRip has the capacity to associate with three aminoacyl-tRNA synthetases (aaRS), the glutamyl- (ERS), glutaminyl- (QRS), and methionyl- (MRS) tRNA synthetases. In eukaryotes, such multi-aaRSs complexes (MSC) regulate the moonlighting activities of aaRSs. In Plasmodium, tRip and the three aaRSs all contain an N-terminal GST-like domain involved in the assembly of two independent complexes: the Q-complex (tRip:ERS:QRS) and the M-complex (tRip:ERS:MRS) with a 2:2:2 stoichiometry and in which the association of the GST-like domains of tRip and ERS (tRip-N:ERS-N) is central. In this study, the crystal structure of the N-terminal GST-like domain of ERS was solved and made possible further investigation of the solution architecture of the Q- and M-complexes by small-angle x-ray scattering (SAXS). This strategy relied on the engineering of a tRip-N-ERS-N chimeric protein to study the structural scaffold of both Plasmodium MSCs and confirm the unique homodimerization pattern of tRip in solution. The biological impact of these structural arrangements is discussed.


  • Organizational Affiliation

    Université de Strasbourg, CNRS, Architecture et Réactivité de l'ARN, UPR 9002, Strasbourg, France.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Glutamate--tRNA ligase
A, B, C, D, E
249Plasmodium berghei ANKAMutation(s): 0
Gene Names: PBANKA_1362000
EC: 6.1.1.17
UniProt
Find proteins for A0A509AR09 (Plasmodium berghei (strain Anka))
Explore A0A509AR09
Go to UniProtKB:  A0A509AR09
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A509AR09
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
TB
Query on TB

Download Ideal Coordinates CCD File
AA [auth C]
BA [auth C]
CA [auth D]
DA [auth D]
EA [auth D]
AA [auth C],
BA [auth C],
CA [auth D],
DA [auth D],
EA [auth D],
FA [auth D],
GA [auth E],
HA [auth E],
IA [auth E],
J [auth A],
JA [auth E],
K [auth A],
L [auth A],
M [auth A],
N [auth A],
O [auth A],
P [auth A],
T [auth B],
U [auth B],
V [auth B],
Y [auth C],
Z [auth C]
TERBIUM(III) ION
Tb
HKCRVXUAKWXBLE-UHFFFAOYSA-N
SO4
Query on SO4

Download Ideal Coordinates CCD File
F [auth A],
G [auth A],
Q [auth B],
R [auth B],
W [auth C]
SULFATE ION
O4 S
QAOWNCQODCNURD-UHFFFAOYSA-L
GOL
Query on GOL

Download Ideal Coordinates CCD File
H [auth A],
I [auth A],
S [auth B],
X [auth C]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.17 Å
  • R-Value Free: 0.237
  • R-Value Work: 0.192
  • R-Value Observed: 0.194
  • Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 130.11α = 90
b = 88.51β = 105.7
c = 168.64γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
CRANK2phasing
XSCALEdata scaling
XDSdata reduction
MxCuBEdata collection

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Agence Nationale de la Recherche (ANR)FranceANR-10-IDEX-0002
Agence Nationale de la Recherche (ANR)FranceANR 20-SFRI-0012
Agence Nationale de la Recherche (ANR)FranceANR-17-EURE-0023

Revision History  (Full details and data files)

  • Version 1.0: 2023-01-25
    Type: Initial release
  • Version 1.1: 2023-02-08
    Changes: Database references
