8AYP

NaK C-DI mutant with Rb+ and Ba2+


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.267
  • R-Value Work: 0.226
  • R-Value Observed: 0.228

wwPDB Validation   3D Report Full Report


This is version 1.2 of the entry. See complete history


Literature

Mechanism of Calcium Permeation in a Glutamate Receptor Ion Channel.

Schackert, F.K.Biedermann, J.Abdolvand, S.Minniberger, S.Song, C.Plested, A.J.R.Carloni, P.Sun, H.

(2023) J Chem Inf Model 63: 1293-1300

  • DOI: https://doi.org/10.1021/acs.jcim.2c01494
  • Primary Citation of Related Structures:
    8AYP, 8AYQ

  • PubMed Abstract:

    The α-amino-3-hydroxy-5-methyl-4-isoxazolepropionic acid receptors (AMPARs) are neurotransmitter-activated cation channels ubiquitously expressed in vertebrate brains. The regulation of calcium flux through the channel pore by RNA-editing is linked to synaptic plasticity while excessive calcium influx poses a risk for neurodegeneration. Unfortunately, the molecular mechanisms underlying this key process are mostly unknown. Here, we investigated calcium conduction in calcium-permeable AMPAR using Molecular Dynamics (MD) simulations with recently introduced multisite force-field parameters for Ca 2+ . Our calculations are consistent with experiment and explain the distinct calcium permeability in different RNA-edited forms of GluA2. For one of the identified metal binding sites, multiscale Quantum Mechanics/Molecular Mechanics (QM/MM) simulations further validated the results from MD and revealed small but reproducible charge transfer between the metal ion and its first solvation shell. In addition, the ion occupancy derived from MD simulations independently reproduced the Ca 2+ binding profile in an X-ray structure of an NaK channel mimicking the AMPAR selectivity filter. This integrated study comprising X-ray crystallography, multisite MD, and multiscale QM/MM simulations provides unprecedented insights into Ca 2+ permeation mechanisms in AMPARs, and paves the way for studying other biological processes in which Ca 2+ plays a pivotal role.


  • Organizational Affiliation

    Computational Biomedicine (IAS-5/INM-9), Forschungszentrum Jülich GmbH, 52428 Jülich, Germany.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Potassium channel proteinA,
B [auth C],
C [auth D],
D [auth B]
96Bacillus cereus ATCC 14579Mutation(s): 3
Gene Names: BC_0669
Membrane Entity: Yes
UniProt
Find proteins for Q81HW2 (Bacillus cereus (strain ATCC 14579 / DSM 31 / CCUG 7414 / JCM 2152 / NBRC 15305 / NCIMB 9373 / NCTC 2599 / NRRL B-3711))
Explore Q81HW2
Go to UniProtKB:  Q81HW2
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ81HW2
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
BA (Subject of Investigation/LOI)
Query on BA

Download Ideal Coordinates CCD File
EA [auth D],
I [auth A],
J [auth A],
U [auth C]
BARIUM ION
Ba
XDFCIPNJCBUZJN-UHFFFAOYSA-N
MPD
Query on MPD

Download Ideal Coordinates CCD File
AA [auth D]
BA [auth D]
CA [auth D]
E [auth A]
F [auth A]
AA [auth D],
BA [auth D],
CA [auth D],
E [auth A],
F [auth A],
FA [auth B],
GA [auth B],
HA [auth B],
IA [auth B],
JA [auth B],
K [auth C],
KA [auth B],
L [auth C],
LA [auth B],
M [auth C],
MA [auth B],
N [auth C],
NA [auth B],
O [auth C],
OA [auth B],
P [auth C],
Q [auth C],
R [auth C],
S [auth C],
V [auth D],
W [auth D],
X [auth D],
Y [auth D],
Z [auth D]
(4S)-2-METHYL-2,4-PENTANEDIOL
C6 H14 O2
SVTBMSDMJJWYQN-YFKPBYRVSA-N
RB (Subject of Investigation/LOI)
Query on RB

Download Ideal Coordinates CCD File
DA [auth D],
G [auth A],
H [auth A],
T [auth C]
RUBIDIUM ION
Rb
NCCSSGKUIKYAJD-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.10 Å
  • R-Value Free: 0.267
  • R-Value Work: 0.226
  • R-Value Observed: 0.228
  • Space Group: C 2 2 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 68.171α = 90
b = 177.495β = 90
c = 68.042γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XSCALEdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
European Research Council (ERC)European Union647895
German Research Foundation (DFG)Germany291198853
German Research Foundation (DFG)Germany323514590
German Research Foundation (DFG)Germany446182550

Revision History  (Full details and data files)

  • Version 1.0: 2023-02-22
    Type: Initial release
  • Version 1.1: 2023-03-08
    Changes: Database references
  • Version 1.2: 2024-02-07
    Changes: Data collection, Refinement description
