8AVP

Structure of short biotin complexed agroavidin with the Hoef tail.


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.87 Å
  • R-Value Free: 0.297
  • R-Value Work: 0.231
  • R-Value Observed: 0.234

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

Self-assembly of a dimeric avidin into unique higher-order oligomers.

Bana, J.Warwar, J.Bayer, E.A.Livnah, O.

(2023) FEBS J 290: 3563-3579

  • DOI: https://doi.org/10.1111/febs.16764
  • Primary Citation of Related Structures:
    8AMH, 8AN6, 8ASR, 8ASS, 8AST, 8ASU, 8AVJ, 8AVP

  • PubMed Abstract:

    The dimeric avidin family has been expanded in recent years to include many new members. All of them lack the intermonomeric Trp that plays a critical role in biotin-binding. Nevertheless, these new members of the avidins maintain the high affinity towards biotin. Additionally, all of the dimeric avidins share a very unique property: namely, the cylindrical oligomerization in the crystal structure. The newest member described here, agroavidin from the agrobacterium, Rhizobium sp. AAP43, shares their important structural features. However, the affinity of agroavidin towards biotin is lower than all other members of the avidin family, due to the presence of phenylalanine instead of a conserved tyrosine in the biotin-binding site. Mutating this phenylalanine into tyrosine regenerated the high affinity, which emphasizes the importance of this particular tyrosine residue. Another unique feature that distinguishes agroavidin from the other dimeric avidins is that it does not produce oligomers in its crystal structure. In order to understand the factors that promote oligomerization in dimeric avidins, we exchanged the C-terminal region of agroavidin with that of hoefavidin that produced octamers. This exchange resulted in a decamer rather than an octamer. This unusual outcome demonstrates the impact of the C-terminal region on the ability to produce oligomers. The decameric assembly of agroavidin expands the avidin-biotin toolbox even further and could well pave the path into new biotin-based technologies. Moreover, uncovering the factors that induce dimeric avidins into oligomeric assemblies may aid in better understanding the general molecular determinants that promote oligomerization.


  • Organizational Affiliation

    Department of Biological Chemistry, The Wolfson Centre for Applied Structural Biology, Alexander Silverman Institute of Life Sciences, The Edmond J. Safra Campus, The Hebrew University of Jerusalem, Israel.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
agroavCH131Rhizobium sp. AAP43Mutation(s): 0
Gene Names: IP76_08565
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
BTN (Subject of Investigation/LOI)
Query on BTN

Download Ideal Coordinates CCD File
AA [auth G]
BA [auth H]
CA [auth I]
DA [auth J]
EA [auth K]
AA [auth G],
BA [auth H],
CA [auth I],
DA [auth J],
EA [auth K],
FA [auth L],
GA [auth M],
HA [auth N],
IA [auth O],
JA [auth P],
KA [auth S],
LA [auth T],
MA [auth Q],
NA [auth R],
U [auth A],
V [auth B],
W [auth C],
X [auth D],
Y [auth E],
Z [auth F]
BIOTIN
C10 H16 N2 O3 S
YBJHBAHKTGYVGT-ZKWXMUAHSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.87 Å
  • R-Value Free: 0.297
  • R-Value Work: 0.231
  • R-Value Observed: 0.234
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 143.106α = 90
b = 81.576β = 114.87
c = 170.05γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
MOSFLMdata reduction
XDSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Israel Science FoundationIsrael--

Revision History  (Full details and data files)

  • Version 1.0: 2023-04-12
    Type: Initial release
  • Version 1.1: 2023-08-02
    Changes: Database references
  • Version 1.2: 2024-02-07
    Changes: Data collection, Refinement description
