8ATE | pdb_00008ate

Galacturonic acid oxidase from Citrus sinensis

PDB DOI: https://doi.org/10.2210/pdb8ATE/pdb

Classification: FLAVOPROTEIN
Organism(s): Citrus sinensis
Expression System: Komagataella pastoris
Mutation(s): No

Deposited: 2022-08-23 Released: 2023-09-06
Deposition Author(s): Boverio, A., Savino, S., Fraaije, M.W., Loncar, N.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.92 Å
R-Value Free:
0.244 (Depositor), 0.249 (DCC)
R-Value Work:
0.205 (Depositor)
R-Value Observed:
0.207 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.3 of the entry. See complete history.

Literature

Biochemical and Structural Characterization of a Uronic Acid Oxidase from Citrus sinensis

Boverio, A., van Beek, H.L., Savino, S., Ranoux, A., Huijgen, W.J.J., Raaijmakers, H.W.C., Fraaije, M.W., Loncar, N.

(2023) ChemCatChem

DOI: https://doi.org/10.1002/cctc.202300847

Macromolecule Content

Total Structure Weight: 58.86 kDa
Atom Count: 4,157
Modeled Residue Count: 502
Deposited Residue Count: 509
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
FAD-binding PCMH-type domain-containing protein	A	509	Citrus sinensis	Mutation(s): 0 Gene Names: CISIN_1g015646mg
UniProt
Find proteins for V4TNJ4 (Citrus clementina) Explore V4TNJ4 Go to UniProtKB: V4TNJ4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	V4TNJ4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 7 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
FAD (Subject of Investigation/LOI) Query on FAD Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	FLAVIN-ADENINE DINUCLEOTIDE C₂₇ H₃₃ N₉ O₁₅ P₂ VWWQXMAJTJZDQX-UYBVJOGSSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
NAG Query on NAG Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
IOD Query on IOD Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A]	E [auth A], F [auth A]	IODIDE ION I XMBWDFGMSWQBCA-UHFFFAOYSA-M		Interactions Focus chain E [auth A] Focus chain F [auth A] Interactions & Density Focus chain E [auth A] Focus chain F [auth A]
PEG Query on PEG Download:Ideal Coordinates CCD File SDF format, chain J [auth A] MOL2 format, chain J [auth A] mmCIF format, chain J [auth A]	J [auth A]	DI(HYDROXYETHYL)ETHER C₄ H₁₀ O₃ MTHSVFCYNBDYFN-UHFFFAOYSA-N		Interactions Focus chain J [auth A] Interactions & Density Focus chain J [auth A]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain I [auth A] MOL2 format, chain I [auth A] mmCIF format, chain I [auth A]	I [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Interactions & Density Focus chain I [auth A]
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
NA Query on NA Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain H [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A]	G [auth A], H [auth A]	SODIUM ION Na FKNQFGJONOIPTF-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain H [auth A] Interactions & Density Focus chain G [auth A] Focus chain H [auth A]
