8A3U | pdb_00008a3u

Crystal structure of a chimeric LOV-Histidine kinase SB2F1 (symmetrical variant, trigonal form with short c-axis)

• PDB DOI: https://doi.org/10.2210/pdb8A3U/pdb

• Classification: SIGNALING PROTEIN
• Organism(s): Pseudomonas putida KT2440, Bradyrhizobium diazoefficiens USDA 110
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2022-06-09 Released: 2023-12-20
• Deposition Author(s): Arinkin, V., Batra-Safferling, R., Granzin, J.
• Funding Organization(s): German Federal Ministry for Education and Research

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.33 Å
• R-Value Free:
  0.280 (Depositor), 0.290 (DCC)
• R-Value Work:
  0.232 (Depositor), 0.240 (DCC)
• R-Value Observed:
  0.234 (Depositor)

Literature

Crystal structure of a chimeric LOV-Histidine kinase SB2F1 (symmetrical variant, trigonal form with short c-axis)

Arinkin, V., Batra-Safferling, R., Granzin, J., Krauss, U.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 44.33 kDa
• Atom Count: 2,891
• Modeled Residue Count: 364
• Deposited Residue Count: 388
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Putative Sensory box protein,Sensor protein FixL	A	388	Pseudomonas putida KT2440, Bradyrhizobium diazoefficiens USDA 110 This entity is chimeric	Mutation(s): 0  Gene Names: PP_2739, fixL, bll2760 EC: 2.7.13.3
UniProt
Find proteins for P23222 (Bradyrhizobium diazoefficiens (strain JCM 10833 / BCRC 13528 / IAM 13628 / NBRC 14792 / USDA 110)) Explore P23222  Go to UniProtKB:  P23222
Find proteins for Q88JB0 (Pseudomonas putida (strain ATCC 47054 / DSM 6125 / CFBP 8728 / NCIMB 11950 / KT2440)) Explore Q88JB0  Go to UniProtKB:  Q88JB0
UniProt Groups	P23222Q88JB0

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ATP (Subject of Investigation/LOI)	B [auth A]	ADENOSINE-5'-TRIPHOSPHATE C10 H16 N5 O13 P3 ZKHQWZAMYRWXGA-KQYNXXCUSA-N
FMN (Subject of Investigation/LOI)	C [auth A]	FLAVIN MONONUCLEOTIDE C17 H21 N4 O9 P FVTCRASFADXXNN-SCRDCRAPSA-N

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE	A	L-PEPTIDE LINKING	C5 H11 N O2 Se		MET

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.33 Å
• R-Value Free:  0.280 (Depositor), 0.290 (DCC)
• R-Value Work:  0.232 (Depositor), 0.240 (DCC)
• R-Value Observed: 0.234 (Depositor)

Space Group: P 3₂ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 138.716	α = 90
b = 138.716	β = 90
c = 49.346	γ = 120

Software Package:

Software Name	Purpose
MxCuBE	data collection
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
SHELXD	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2023-12-20
Deposition Author(s): Arinkin, V., Batra-Safferling, R., Granzin, J.

---

Funding Organization	Location	Grant Number
German Federal Ministry for Education and Research	Germany	OptoSys, FKZ 031A16

Revision History

• Version 1.0: 2023-12-20
  Type: Initial release

• Version 1.1: 2024-10-16
  Changes: Structure summary
