 7YFW | pdb_00007yfw

Cyanophage Pam3 fiber


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.96 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 7YFW

This is version 1.2 of the entry. See complete history.

Literature

Fine structure and assembly pattern of a minimal myophage Pam3.

Yang, F., Jiang, Y.L., Zhang, J.T., Zhu, J., Du, K., Yu, R.C., Wei, Z.L., Kong, W.W., Cui, N., Li, W.F., Chen, Y., Li, Q., Zhou, C.Z.

(2023) Proc Natl Acad Sci U S A 120: e2213727120-e2213727120

  • DOI: https://doi.org/10.1073/pnas.2213727120
  • Primary Citation Related Structures:
    7YFW, 7YFZ, 8HDR, 8HDS, 8HDT, 8HDW

  • PubMed Abstract:

    The myophage possesses a contractile tail that penetrates its host cell envelope. Except for investigations on the bacteriophage T4 with a rather complicated structure, the assembly pattern and tail contraction mechanism of myophage remain largely unknown. Here, we present the fine structure of a freshwater Myoviridae cyanophage Pam3, which has an icosahedral capsid of ~680 Å in diameter, connected via a three-section neck to an 840-Å-long contractile tail, ending with a three-module baseplate composed of only six protein components. This simplified baseplate consists of a central hub-spike surrounded by six wedge heterotriplexes, to which twelve tail fibers are covalently attached via disulfide bonds in alternating upward and downward configurations. In vitro reduction assays revealed a putative redox-dependent mechanism of baseplate assembly and tail sheath contraction. These findings establish a minimal myophage that might become a user-friendly chassis phage in synthetic biology.


  • Organizational Affiliation:
    • School of Life Sciences, Division of Life Sciences and Medicine, University of Science and Technology of China, Hefei 230026, China.

Macromolecule Content

  • Total Structure Weight: 81.97 kDa
  • Atom Count: 5,772
  • Modeled Residue Count: 840
  • Deposited Residue Count: 840
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Pam3 fiber proreinsA [auth a],
B [auth b],
C [auth c]
280uncultured cyanophageMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.96 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION3.1

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Ministry of Science and Technology (MoST, China)China2018YFA0903100

Revision History  (Full details and data files)

  • Version 1.0: 2023-01-18
    Type: Initial release
  • Version 1.1: 2023-02-01
    Changes: Database references
  • Version 1.2: 2024-07-03
    Changes: Data collection
