7YD1 | pdb_00007yd1

Local refinement of SARS-CoV-2 Omicron S trimer complexed with XG005

PDB DOI: https://doi.org/10.2210/pdb7YD1/pdb
EM Map EMD-33745: EMDB EMDataResource

Classification: VIRAL PROTEIN
Organism(s): Severe acute respiratory syndrome coronavirus 2, Homo sapiens
Expression System: Homo sapiens
Mutation(s): Yes

Deposited: 2022-07-02 Released: 2023-07-12
Deposition Author(s): Zhan, W.Q., Zhang, X., Chen, Z.G., Sun, L.
Funding Organization(s): Ministry of Science and Technology (MoST, China)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.99 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 7YD1

This is version 1.2 of the entry. See complete history.

Literature

OS-XG005

Zhan, W.Q., Zhang, X.

To be published.

Macromolecule Content

Total Structure Weight: 47.01 kDa
Atom Count: 3,305
Modeled Residue Count: 428
Deposited Residue Count: 428
Unique protein chains: 3

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Spike protein S1	A [auth C]	198	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 15 Gene Names: S, 2
UniProt
Find proteins for P0DTC2 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTC2 Go to UniProtKB: P0DTC2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P0DTC2
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
XG005-VH	B [auth A]	122	Homo sapiens	Mutation(s): 0

Find similar proteins by:

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
XG005-VL	C [auth B]	108	Homo sapiens	Mutation(s): 0

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.99 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2023-07-12

Deposition Author(s):

Funding Organization	Location	Grant Number
Ministry of Science and Technology (MoST, China)	China	2021YFC2302500

Revision History (Full details and data files)

Version 1.0: 2023-07-12
Type: Initial release
Version 1.1: 2024-10-23
Changes: Data collection, Structure summary
Version 1.2: 2025-07-02
Changes: Data collection
