7UZ8

Structure of the SARS-CoV-2 Omicron BA.1 S 6P trimer in complex with the mouse antibody Fab fragment, M8a-31

PDB DOI: https://doi.org/10.2210/pdb7UZ8/pdb
EM Map EMD-26882: EMDB EMDataResource

Classification: IMMUNE SYSTEM/VIRAL PROTEIN
Organism(s): Severe acute respiratory syndrome coronavirus 2, Mus musculus
Expression System: Homo sapiens
Mutation(s): Yes

Deposited: 2022-05-08 Released: 2022-12-07
Deposition Author(s): Fan, C., Bjorkman, P.J.
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.10 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.2 of the entry. See complete history.

Macromolecule Content

Total Structure Weight: 571.74 kDa
Atom Count: 30,075
Modelled Residue Count: 3,801
Deposited Residue Count: 5,103
Unique protein chains: 3

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Spike glycoprotein	A, B, C	1,253	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 40 Gene Names: S, 2
UniProt
Find proteins for P0DTC2 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTC2 Go to UniProtKB: P0DTC2
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P0DTC2
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
M8a-31 Fab heavy chain	D [auth H], F [auth M], H [auth P]	228	Mus musculus	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
M8a-31 Fab light chain	E [auth L], G [auth N], I [auth Q]	220	Mus musculus	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 4
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	J [auth D], K [auth E], L [auth F]	2	N/A	N-Glycosylation	Interactions Focus chain J [auth D] Focus chain K [auth E] Focus chain L [auth F] Interactions & Density Focus chain J [auth D] Focus chain K [auth E] Focus chain L [auth F]
Glycosylation Resources
GlyTouCan: G42666HT GlyCosmos: G42666HT GlyGen: G42666HT

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG (Subject of Investigation/LOI) Query on NAG Download Ideal Coordinates CCD File SDF format, chain AA [auth B] SDF format, chain BA [auth B] SDF format, chain CA [auth B] SDF format, chain DA [auth B] SDF format, chain EA [auth C] SDF format, chain FA [auth C] SDF format, chain GA [auth C] SDF format, chain HA [auth C] SDF format, chain IA [auth C] SDF format, chain JA [auth C] SDF format, chain KA [auth C] SDF format, chain LA [auth C] SDF format, chain M [auth A] SDF format, chain MA [auth C] SDF format, chain N [auth A] SDF format, chain O [auth A] SDF format, chain P [auth A] SDF format, chain Q [auth A] SDF format, chain R [auth A] SDF format, chain S [auth A] SDF format, chain T [auth A] SDF format, chain U [auth A] SDF format, chain V [auth B] SDF format, chain W [auth B] SDF format, chain X [auth B] SDF format, chain Y [auth B] SDF format, chain Z [auth B] MOL2 format, chain AA [auth B] MOL2 format, chain BA [auth B] MOL2 format, chain CA [auth B] MOL2 format, chain DA [auth B] MOL2 format, chain EA [auth C] MOL2 format, chain FA [auth C] MOL2 format, chain GA [auth C] MOL2 format, chain HA [auth C] MOL2 format, chain IA [auth C] MOL2 format, chain JA [auth C] MOL2 format, chain KA [auth C] MOL2 format, chain LA [auth C] MOL2 format, chain M [auth A] MOL2 format, chain MA [auth C] MOL2 format, chain N [auth A] MOL2 format, chain O [auth A] MOL2 format, chain P [auth A] MOL2 format, chain Q [auth A] MOL2 format, chain R [auth A] MOL2 format, chain S [auth A] MOL2 format, chain T [auth A] MOL2 format, chain U [auth A] MOL2 format, chain V [auth B] MOL2 format, chain W [auth B] MOL2 format, chain X [auth B] MOL2 format, chain Y [auth B] MOL2 format, chain Z [auth B]	AA [auth B] BA [auth B] CA [auth B] DA [auth B] EA [auth C] AA [auth B], BA [auth B], CA [auth B], DA [auth B], EA [auth C], FA [auth C], GA [auth C], HA [auth C], IA [auth C], JA [auth C], KA [auth C], LA [auth C], M [auth A], MA [auth C], N [auth A], O [auth A], P [auth A], Q [auth A], R [auth A], S [auth A], T [auth A], U [auth A], V [auth B], W [auth B], X [auth B], Y [auth B], Z [auth B]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain AA [auth B] Focus chain BA [auth B] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain EA [auth C] Focus chain FA [auth C] Focus chain GA [auth C] Focus chain HA [auth C] Focus chain IA [auth C] Focus chain JA [auth C] Focus chain KA [auth C] Focus chain LA [auth C] Focus chain M [auth A] Focus chain MA [auth C] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B] Interactions & Density Focus chain AA [auth B] Focus chain BA [auth B] Focus chain CA [auth B] Focus chain DA [auth B] Focus chain EA [auth C] Focus chain FA [auth C] Focus chain GA [auth C] Focus chain HA [auth C] Focus chain IA [auth C] Focus chain JA [auth C] Focus chain KA [auth C] Focus chain LA [auth C] Focus chain M [auth A] Focus chain MA [auth C] Focus chain N [auth A] Focus chain O [auth A] Focus chain P [auth A] Focus chain Q [auth A] Focus chain R [auth A] Focus chain S [auth A] Focus chain T [auth A] Focus chain U [auth A] Focus chain V [auth B] Focus chain W [auth B] Focus chain X [auth B] Focus chain Y [auth B] Focus chain Z [auth B]
