7RTZ | pdb_00007rtz

X-ray crystallographic structure of a beta-hairpin peptide derived from amyloid beta 14-40

PDB DOI: https://doi.org/10.2210/pdb7RTZ/pdb

Classification: DE NOVO PROTEIN
Organism(s): Homo sapiens
Mutation(s): No

Deposited: 2021-08-16 Released: 2022-08-31
Deposition Author(s): Samdin, T.D., Kreutzer, A.G., Nowick, J.S.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS), National Institutes of Health/National Institute on Aging (NIH/NIA)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free:
0.293 (Depositor), 0.291 (DCC)
R-Value Work:
0.263 (Depositor), 0.264 (DCC)
R-Value Observed:
0.266 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7RTZ

This is version 1.2 of the entry. See complete history.

Literature

A beta-Barrel-Like Tetramer Formed by a beta-Hairpin Derived From A beta

Samdin, T.D., Jones, C.R., Guaglianone, G., Kreutzer, A.G., Freites, J.A., Wierzbicki, M., Nowick, J.S.

(2023) Chem Sci

DOI: https://doi.org/10.1039/D3SC05185D

Macromolecule Content

Total Structure Weight: 5.3 kDa
Atom Count: 376
Modeled Residue Count: 48
Deposited Residue Count: 48
Unique protein chains: 1

Macromolecules

Find similar proteins by: Sequence | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Amyloid-beta protein 40	A, B	24	Homo sapiens	Mutation(s): 0
UniProt & NIH Common Fund Data Resources
Find proteins for P05067 (Homo sapiens) Explore P05067 Go to UniProtKB: P05067
PHAROS: P05067 GTEx: ENSG00000142192
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P05067
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
CL Query on CL Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Modified Residues 2 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
ORN Query on ORN	A, B	L-PEPTIDE LINKING	C₅ H₁₂ N₂ O₂		ALA
SAR Query on SAR	A, B	PEPTIDE LINKING	C₃ H₇ N O₂		GLY

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.10 Å
R-Value Free: 0.293 (Depositor), 0.291 (DCC)
R-Value Work: 0.263 (Depositor), 0.264 (DCC)
R-Value Observed: 0.266 (Depositor)

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 44.327	α = 90
b = 44.327	β = 90
c = 64.427	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
XDS	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2022-08-31

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	GM097562
National Institutes of Health/National Institute on Aging (NIH/NIA)	United States	--

Revision History (Full details and data files)

Version 1.0: 2022-08-31
Type: Initial release
Version 1.1: 2023-10-18
Changes: Data collection, Refinement description
Version 1.2: 2023-12-13
Changes: Database references
