7R53

Crystal structure of human TLR8 in complex with Compound 15

PDB DOI: https://doi.org/10.2210/pdb7R53/pdb

Classification: IMMUNE SYSTEM
Organism(s): Homo sapiens
Expression System: Drosophila melanogaster
Mutation(s): No

Deposited: 2022-02-10 Released: 2022-03-23
Deposition Author(s): Faller, M., Zink, F.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 3.12 Å
R-Value Free: 0.269
R-Value Work: 0.238
R-Value Observed: 0.239

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.2 of the entry. See complete history.

Literature

Structure-Based Optimization of a Fragment-like TLR8 Binding Screening Hit to an In Vivo Efficacious TLR7/8 Antagonist.

Betschart, C., Faller, M., Zink, F., Hemmig, R., Blank, J., Vangrevelinghe, E., Bourrel, M., Glatthar, R., Behnke, D., Barker, K., Heizmann, A., Angst, D., Nimsgern, P., Jacquier, S., Junt, T., Zipfel, G., Ruzzante, G., Loetscher, P., Limonta, S., Hawtin, S., Andre, C.B., Boulay, T., Feifel, R., Knoepfel, T.

(2022) ACS Med Chem Lett 13: 658-664

PubMed: 35450354 Search on PubMedSearch on PubMed Central
DOI: https://doi.org/10.1021/acsmedchemlett.1c00696
Primary Citation of Related Structures:
7R52, 7R53, 7R54

PubMed Abstract:
Inappropriate activation of TLR7 and TLR8 is linked to several autoimmune diseases, such as lupus erythematosus. Here we report on the efficient structure-based optimization of the inhibition of TLR8, starting from a co-crystal structure of a small screening hit. Further optimization of the physicochemical properties for cellular potency and expansion of the structure-activity relationship for dual potency finally resulted in a highly potent TLR7/8 antagonist with demonstrated in vivo efficacy after oral dosing.

Organizational Affiliation

Global Discovery Chemistry, Novartis Institutes for BioMedical Research, CH-4002 Basel, Switzerland.

Macromolecule Content

Total Structure Weight: 192.85 kDa
Atom Count: 12,272
Modelled Residue Count: 1,473
Deposited Residue Count: 1,614
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Toll-like receptor 8	A, B	807	Homo sapiens	Mutation(s): 0 Gene Names: TLR8, UNQ249/PRO286
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NR97 (Homo sapiens) Explore Q9NR97 Go to UniProtKB: Q9NR97
PHAROS: Q9NR97 GTEx: ENSG00000101916
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9NR97
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
alpha-D-mannopyranose-(1-3)-[alpha-D-mannopyranose-(1-6)]beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	C, E, F, H	5		N-Glycosylation	Interactions Focus chain C Focus chain E Focus chain F Focus chain H Interactions & Density Focus chain C Focus chain E Focus chain F Focus chain H
Glycosylation Resources
GlyTouCan: G22768VO GlyCosmos: G22768VO GlyGen: G22768VO

Entity ID: 3
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	D, G	3		N-Glycosylation	Interactions Focus chain D Focus chain G Interactions & Density Focus chain D Focus chain G
Glycosylation Resources
GlyTouCan: G15407YE GlyCosmos: G15407YE GlyGen: G15407YE

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
I5N (Subject of Investigation/LOI) Query on I5N Download Ideal Coordinates CCD File SDF format, chain O [auth A] SDF format, chain P [auth A] MOL2 format, chain O [auth A] MOL2 format, chain P [auth A]	O [auth A], P [auth A]	5-cyclopropyl-6-(2,6-dimethylpyridin-4-yl)-~{N}-[(3~{R},4~{R})-3-fluoranylpiperidin-4-yl]-1~{H}-indazol-3-amine C₂₂ H₂₆ F N₅ JUSJRQVEHUHMRQ-WOJBJXKFSA-N		Interactions Focus chain O [auth A] Focus chain P [auth A] Interactions & Density Focus chain O [auth A] Focus chain P [auth A]
NAG Query on NAG Download Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain M [auth A] SDF format, chain N [auth A] SDF format, chain Q [auth B] SDF format, chain R [auth B] SDF format, chain S [auth B] SDF format, chain T [auth B] SDF format, chain U [auth B] SDF format, chain V [auth B] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain M [auth A] MOL2 format, chain N [auth A] MOL2 format, chain Q [auth B] MOL2 format, chain R [auth B] MOL2 format, chain S [auth B] MOL2 format, chain T [auth B] MOL2 format, chain U [auth B] MOL2 format, chain V [auth B]	I [auth A] J [auth A] K [auth A] L [auth A] M [auth A] I [auth A], J [auth A], K [auth A], L [auth A], M [auth A], N [auth A], Q [auth B], R [auth B], S [auth B], T [auth B], U [auth B], V [auth B]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B] Interactions & Density Focus chain I [auth A] Focus chain J [auth A] Focus chain K [auth A] Focus chain L [auth A] Focus chain M [auth A] Focus chain N [auth A] Focus chain Q [auth B] Focus chain R [auth B] Focus chain S [auth B] Focus chain T [auth B] Focus chain U [auth B] Focus chain V [auth B]
