7QHS

S. cerevisiae CMGE nucleating origin DNA melting


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.30 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Models: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.3 of the entry. See complete history


Literature

Mechanism of replication origin melting nucleated by CMG helicase assembly.

Lewis, J.S.Gross, M.H.Sousa, J.Henrikus, S.S.Greiwe, J.F.Nans, A.Diffley, J.F.X.Costa, A.

(2022) Nature 606: 1007-1014

  • DOI: https://doi.org/10.1038/s41586-022-04829-4
  • Primary Citation of Related Structures:
    7QHS, 7Z13

  • PubMed Abstract:

    The activation of eukaryotic origins of replication occurs in temporally separated steps to ensure that chromosomes are copied only once per cell cycle. First, the MCM helicase is loaded onto duplex DNA as an inactive double hexamer. Activation occurs after the recruitment of a set of firing factors that assemble two Cdc45-MCM-GINS (CMG) holo-helicases. CMG formation leads to the underwinding of DNA on the path to the establishment of the replication fork, but whether DNA becomes melted at this stage is unknown 1 . Here we use cryo-electron microscopy to image ATP-dependent CMG assembly on a chromatinized origin, reconstituted in vitro with purified yeast proteins. We find that CMG formation disrupts the double hexamer interface and thereby exposes duplex DNA in between the two CMGs. The two helicases remain tethered, which gives rise to a splayed dimer, with implications for origin activation and replisome integrity. Inside each MCM ring, the double helix becomes untwisted and base pairing is broken. This comes as the result of ATP-triggered conformational changes in MCM that involve DNA stretching and protein-mediated stabilization of three orphan bases. Mcm2 pore-loop residues that engage DNA in our structure are dispensable for double hexamer loading and CMG formation, but are essential to untwist the DNA and promote replication. Our results explain how ATP binding nucleates origin DNA melting by the CMG and maintains replisome stability at initiation.


  • Organizational Affiliation

    Macromolecular Machines Laboratory, The Francis Crick Institute, London, UK.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DNA replication licensing factor MCM2A [auth 2]868Saccharomyces cerevisiaeMutation(s): 0
Gene Names: PACBIOSEQ_LOCUS187PACBIOSEQ_LOCUS193PACBIOSEQ_LOCUS195PACBIOSEQ_LOCUS196SCNYR20_0007007400SCP684_0007007100
EC: 3.6.4.12
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
DNA replication licensing factor MCM3B [auth 3]1,006Saccharomyces cerevisiaeMutation(s): 0
Gene Names: MCM3YEL032WSYGP-ORF23
EC: 3.6.4.12
UniProt
Find proteins for P24279 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P24279
Go to UniProtKB:  P24279
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP24279
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
DNA replication licensing factor MCM4C [auth 4]933Saccharomyces cerevisiaeMutation(s): 0
Gene Names: MCM4CDC54HCD21YPR019WYP9531.13
EC: 3.6.4.12
UniProt
Find proteins for P30665 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P30665
Go to UniProtKB:  P30665
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP30665
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
DNA replication licensing factor MCM6D [auth 6]1,017Saccharomyces cerevisiaeMutation(s): 0
Gene Names: MCM6YGL201C
EC: 3.6.4.12
UniProt
Find proteins for P53091 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P53091
Go to UniProtKB:  P53091
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP53091
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
DNA replication licensing factor MCM7E [auth 7]845Saccharomyces cerevisiaeMutation(s): 0
Gene Names: MCM7CDC47YBR202WYBR1441
EC: 3.6.4.12
UniProt
Find proteins for P38132 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P38132
Go to UniProtKB:  P38132
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP38132
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 6
MoleculeChains Sequence LengthOrganismDetailsImage
DNA replication complex GINS protein PSF1F [auth H]208Saccharomyces cerevisiaeMutation(s): 0
Gene Names: PACBIOSEQ_LOCUS944PACBIOSEQ_LOCUS956PACBIOSEQ_LOCUS958SCNYR20_0001022500SCP684_0001022000
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 7
MoleculeChains Sequence LengthOrganismDetailsImage
DNA replication complex GINS protein PSF2G [auth I]213Saccharomyces cerevisiaeMutation(s): 0
Gene Names: PACBIOSEQ_LOCUS3163PACBIOSEQ_LOCUS3191PACBIOSEQ_LOCUS3224PACBIOSEQ_LOCUS3231PACBIOSEQ_LOCUS3255SCNYR20_0009012300SCP684_0009011800
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 8
MoleculeChains Sequence LengthOrganismDetailsImage
DNA replication complex GINS protein PSF3H [auth C]229Saccharomyces cerevisiaeMutation(s): 0
Gene Names: PSF3YOL146W
UniProt
Find proteins for Q12146 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q12146
Go to UniProtKB:  Q12146
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ12146
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 9
MoleculeChains Sequence LengthOrganismDetailsImage
DNA replication complex GINS protein SLD5I [auth D]294Saccharomyces cerevisiaeMutation(s): 0
Gene Names: SLD5YDR489W
UniProt
Find proteins for Q03406 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q03406
Go to UniProtKB:  Q03406
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ03406
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 10
MoleculeChains Sequence LengthOrganismDetailsImage
Cell division control protein 45J [auth E]657Saccharomyces cerevisiaeMutation(s): 0
Gene Names: CDC45SLD4YLR103CL8004.11
UniProt
Find proteins for Q08032 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore Q08032
Go to UniProtKB:  Q08032
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ08032
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 11
MoleculeChains Sequence LengthOrganismDetailsImage
DNA polymerase epsilon subunit BK [auth F]689Saccharomyces cerevisiaeMutation(s): 0
Gene Names: DPB2YPR175WP9705.7
UniProt
Find proteins for P24482 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P24482
Go to UniProtKB:  P24482
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP24482
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 12
MoleculeChains Sequence LengthOrganismDetailsImage
DNA polymerase epsilon catalytic subunit AL [auth G]2,222Saccharomyces cerevisiaeMutation(s): 0
Gene Names: POL2DUN2YNL262WN0825
EC: 2.7.7.7 (PDB Primary Data), 3.1.11 (PDB Primary Data)
UniProt
Find proteins for P21951 (Saccharomyces cerevisiae (strain ATCC 204508 / S288c))
Explore P21951
Go to UniProtKB:  P21951
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP21951
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 15
MoleculeChains Sequence LengthOrganismDetailsImage
DNA replication licensing factor MCM5O [auth 5]775Saccharomyces cerevisiaeMutation(s): 0
Gene Names: PACBIOSEQ_LOCUS4112PACBIOSEQ_LOCUS4129PACBIOSEQ_LOCUS4153PACBIOSEQ_LOCUS4202SCNYR20_0004029000SCP684_0004028600
EC: 3.6.4.12
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 13
MoleculeChains LengthOrganismImage
DNA (26-MER)M [auth A]26DNA molecule
Sequence Annotations
Expand
  • Reference Sequence
Find similar nucleic acids by:  (by identity cutoff)  |  3D Structure
Entity ID: 14
MoleculeChains LengthOrganismImage
DNA (26-MER)N [auth B]26DNA molecule
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ATP (Subject of Investigation/LOI)
Query on ATP

Download Ideal Coordinates CCD File
CA [auth 5],
P [auth 2],
R [auth 3],
X [auth 7]
ADENOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O13 P3
ZKHQWZAMYRWXGA-KQYNXXCUSA-N
ADP (Subject of Investigation/LOI)
Query on ADP

Download Ideal Coordinates CCD File
T [auth 4],
V [auth 6]
ADENOSINE-5'-DIPHOSPHATE
C10 H15 N5 O10 P2
XTWYTFMLZFPYCI-KQYNXXCUSA-N
ZN (Subject of Investigation/LOI)
Query on ZN

Download Ideal Coordinates CCD File
AA [auth G]
BA [auth G]
EA [auth 5]
Q [auth 2]
U [auth 4]
AA [auth G],
BA [auth G],
EA [auth 5],
Q [auth 2],
U [auth 4],
W [auth 6],
Z [auth 7]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
MG (Subject of Investigation/LOI)
Query on MG

Download Ideal Coordinates CCD File
DA [auth 5],
S [auth 3],
Y [auth 7]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.30 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION3.1
MODEL REFINEMENTPHENIX1.19.2

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
European Molecular Biology Organization (EMBO)European Union211-2020
H2020 Marie Curie Actions of the European CommissionEuropean Union--
European Molecular Biology Organization (EMBO)European Union1177-2020
Human Frontier Science Program (HFSP)European UnionLT000834/2020-L
European Molecular Biology Organization (EMBO)European Union962-2019
The Francis Crick InstituteEuropean UnionFC001065
The Francis Crick InstituteEuropean UnionFC001066
Wellcome TrustEuropean Union106252/Z/14/Z
European Research Council (ERC)European Union669424-CHROMOREP
European Research Council (ERC)European Union820102

Revision History  (Full details and data files)

  • Version 1.0: 2022-06-15
    Type: Initial release
  • Version 1.1: 2022-06-29
    Changes: Database references
  • Version 1.2: 2022-07-06
    Changes: Database references
  • Version 1.3: 2024-07-17
    Changes: Data collection, Refinement description
