7MHW

Crystal structure of the protease inhibitor U-Omp19 from Brucella abortus fused to Maltose-binding protein


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.55 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.207
  • R-Value Observed: 0.208

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history


Literature

A disordered region retains the full protease inhibitor activity and the capacity to induce CD8 + T cells in vivo of the oral vaccine adjuvant U-Omp19.

Laura Darriba, M.Castro, C.P.Coria, L.M.Bruno, L.Laura Cerutti, M.Otero, L.H.Chemes, L.B.Rasia, R.M.Klinke, S.Cassataro, J.Pasquevich, K.A.

(2022) Comput Struct Biotechnol J 20: 5098-5114

  • DOI: https://doi.org/10.1016/j.csbj.2022.08.054
  • Primary Citation of Related Structures:
    7MHW

  • PubMed Abstract:

    U-Omp19 is a bacterial protease inhibitor from Brucella abortus that inhibits gastrointestinal and lysosomal proteases, enhancing the half-life and immunogenicity of co-delivered antigens. U-Omp19 is a novel adjuvant that is in preclinical development with various vaccine candidates. However, the molecular mechanisms by which it exerts these functions and the structural elements responsible for these activities remain unknown. In this work, a structural, biochemical, and functional characterization of U-Omp19 is presented. Dynamic features of U-Omp19 in solution by NMR and the crystal structure of its C-terminal domain are described. The protein consists of a compact C-terminal beta-barrel domain and a flexible N-terminal domain. The latter domain behaves as an intrinsically disordered protein and retains the full protease inhibitor activity against pancreatic elastase, papain and pepsin. This domain also retains the capacity to induce CD8 + T cells in vivo of U-Omp19. This information may lead to future rationale vaccine designs using U-Omp19 as an adjuvant to deliver other proteins or peptides in oral formulations against infectious diseases, as well as to design strategies to incorporate modifications in its structure that may improve its adjuvanticity.


  • Organizational Affiliation

    Instituto de Investigaciones Biotecnológicas, Universidad Nacional de San Martín (UNSAM) - Consejo Nacional de Investigaciones Científicas y Técnicas (CONICET), Buenos Aires, Argentina.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Maltose/maltodextrin-binding periplasmic protein,Outer membrane lipoprotein omp19481Escherichia coliBrucella abortus 2308
This entity is chimeric
Mutation(s): 6
Gene Names: malEb4034JW3994omp19BAB1_1930
UniProt
Find proteins for P0AEX9 (Escherichia coli (strain K12))
Explore P0AEX9
Go to UniProtKB:  P0AEX9
Find proteins for Q2YLR6 (Brucella abortus (strain 2308))
Explore Q2YLR6
Go to UniProtKB:  Q2YLR6
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupsQ2YLR6P0AEX9
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.55 Å
  • R-Value Free: 0.242
  • R-Value Work: 0.207
  • R-Value Observed: 0.208
  • Space Group: I 41 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 141.67α = 90
b = 141.67β = 90
c = 132.217γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
MxCuBEdata collection
XDSdata reduction
PHENIXphasing
Cootmodel building
PDB_EXTRACTdata extraction
Aimlessdata scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Agencia Nacional de Promocion Cientifica y Tecnologica (FONCYT)ArgentinaPICT-2017-1849
Agencia Nacional de Promocion Cientifica y Tecnologica (FONCYT)ArgentinaPICT-2014-1250
Bill & Melinda Gates FoundationUnited StatesOPP1060394
Bill & Melinda Gates FoundationUnited StatesOPP1119024

Revision History  (Full details and data files)

  • Version 1.0: 2022-04-20
    Type: Initial release
  • Version 1.1: 2022-11-02
    Changes: Database references
  • Version 1.2: 2023-10-18
    Changes: Data collection, Refinement description
