7ZVK

Crystal structure of human STING in complex with 3',3'-c-(2'F,2'dAMP-<carba>IMP)

• PDB DOI: https://doi.org/10.2210/pdb7ZVK/pdb

• Classification: ANTIVIRAL PROTEIN
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2022-05-16 Released: 2023-11-29
• Deposition Author(s): Klima, M., Smola, M., Boura, E.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.83 Å
• R-Value Free: 0.279
• R-Value Work: 0.230
• R-Value Observed: 0.232

Literature

Crystal structure of human STING in complex with 3',3'-c-(2'F,2'dAMP-IMP)

Klima, M., Smola, M., Boura, E.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 47.04 kDa
• Atom Count: 2,833
• Modelled Residue Count: 343
• Deposited Residue Count: 408
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Stimulator of interferon protein	A, B	204	Homo sapiens	Mutation(s): 0  Gene Names: STING, LOC340061, hCG_1782396
UniProt & NIH Common Fund Data Resources
Find proteins for Q86WV6 (Homo sapiens) Explore Q86WV6  Go to UniProtKB:  Q86WV6
PHAROS:  Q86WV6 GTEx:  ENSG00000184584

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
K1L (Subject of Investigation/LOI)	C [auth B]	9-[(1~{R},6~{R},8~{R},9~{R},10~{R},15~{R},17~{R},18~{S})-8-(6-aminopurin-9-yl)-9-fluoranyl-3,12,18-tris(oxidanyl)-3,12-bis(oxidanylidene)-2,4,7,11,13-pentaoxa-3$l^{5},12$l^{5}-diphosphatricyclo[13.3.0.0^{6,10}]octadecan-17-yl]-3~{H}-purin-6-one C21 H24 F N9 O11 P2 SOEFHQXFHXZBEJ-FAWVPDCCSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.83 Å
• R-Value Free: 0.279
• R-Value Work: 0.230
• R-Value Observed: 0.232
• Space Group: I 4₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 145.256	α = 90
b = 145.256	β = 90
c = 36.046	γ = 90

Software Package:

Software Name	Purpose
XDS	data reduction
XDS	data scaling
PHASER	phasing
PHENIX	refinement
Coot	model building

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2023-11-29
Deposition Author(s): Klima, M., Smola, M., Boura, E.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2023-11-29
  Type: Initial release
