7ZRN

Crystal structure of 10-epi-cubebol synthase from Sorangium cellulosum (ScCubS) in complex with Pyrophosphate

  • Classification: PLANT PROTEIN
  • Organism(s): Sorangium cellulosum
  • Expression System: Escherichia coli
  • Mutation(s): No

  • Deposited: 2022-05-04 Released: 2022-11-02
  • Deposition Author(s): Levy, C.W.
  • Funding Organization(s): Biotechnology and Biological Sciences Research Council (BBSRC), Engineering and Physical Sciences Research Council

Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.82 Å
  • R-Value Free: 0.204
  • R-Value Work: 0.175
  • R-Value Observed: 0.176

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

How a 10- epi-Cubebol Synthase Avoids Premature Reaction Quenching to Form a Tricyclic Product at High Purity.

Whitehead, J.N.Leferink, N.G.H.Komati Reddy, G.Levy, C.W.Hay, S.Takano, E.Scrutton, N.S.

(2022) ACS Catal 12: 12123-12131

  • DOI: https://doi.org/10.1021/acscatal.2c03155
  • Primary Citation of Related Structures:
    7ZRN

  • PubMed Abstract:

    Terpenes are the largest class of natural products and are attractive targets in the fuel, fragrance, pharmaceutical, and flavor industries. Harvesting terpenes from natural sources is environmentally intensive and often gives low yields and purities, requiring further downstream processing. Engineered terpene synthases (TSs) offer a solution to these problems, but the low sequence identity and high promiscuity among TSs are major challenges for targeted engineering. Rational design of TSs requires identification of key structural and chemical motifs that steer product outcomes. Producing the sesquiterpenoid 10- epi -cubebol from farnesyl pyrophosphate (FPP) requires many steps and some of Nature's most difficult chemistry. 10- epi -Cubebol synthase from Sorangium cellulosum (ScCubS) guides a highly reactive carbocationic substrate through this pathway, preventing early quenching and ensuring correct stereochemistry at every stage. The cyclizations carried out by ScCubS potentially represent significant evolutionary expansions in the chemical space accessible by TSs. Here, we present the high-resolution crystal structure of ScCubS in complex with both a trinuclear magnesium cluster and pyrophosphate. Computational modeling, experiment, and bioinformatic analysis identified residues important in steering the reaction chemistry. We show that S206 is crucial in 10- epi -cubebol synthesis by enlisting the nearby F211 to shape the active site contour and prevent the formation of early escape cadalane products. We also show that N327 and F104 control the distribution between several early-stage cations and whether the final product is derived from the germacrane, cadalane, or cubebane hydrocarbon scaffold. Using these insights, we reengineered ScCubS so that its main product was germacradien-4-ol, which derives from the germacrane, rather than the cubebane, scaffold. Our work emphasizes that mechanistic understanding of cation stabilization in TSs can be used to guide catalytic outcomes.


  • Organizational Affiliation

    Manchester Institute of Biotechnology, Department of Chemistry, The University of Manchester, Manchester M1 7DN, U.K.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
10-epi-cubebol synthase
A, B
343Sorangium cellulosumMutation(s): 0
Gene Names: sce6369
EC: 4.2.3.175
UniProt
Find proteins for A9GK58 (Sorangium cellulosum (strain So ce56))
Explore A9GK58
Go to UniProtKB:  A9GK58
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA9GK58
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 3 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
PPV
Query on PPV

Download Ideal Coordinates CCD File
C [auth A],
G [auth B]
PYROPHOSPHATE
H4 O7 P2
XPPKVPWEQAFLFU-UHFFFAOYSA-N
ACT
Query on ACT

Download Ideal Coordinates CCD File
H [auth B]ACETATE ION
C2 H3 O2
QTBSBXVTEAMEQO-UHFFFAOYSA-M
MG
Query on MG

Download Ideal Coordinates CCD File
D [auth A]
E [auth A]
F [auth A]
I [auth B]
J [auth B]
D [auth A],
E [auth A],
F [auth A],
I [auth B],
J [auth B],
K [auth B]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.82 Å
  • R-Value Free: 0.204
  • R-Value Work: 0.175
  • R-Value Observed: 0.176
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 74.315α = 90
b = 89.644β = 90
c = 100.563γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
DIALSdata reduction
DIALSdata scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data

  • Released Date: 2022-11-02
  • Deposition Author(s): Levy, C.W.

Funding OrganizationLocationGrant Number
Biotechnology and Biological Sciences Research Council (BBSRC)United KingdomBB/M000354/1
Biotechnology and Biological Sciences Research Council (BBSRC)United KingdomBB/M017702/1
Biotechnology and Biological Sciences Research Council (BBSRC)United KingdomBB/L027593/1
Engineering and Physical Sciences Research CouncilUnited KingdomEP/S01778X/1

Revision History  (Full details and data files)

  • Version 1.0: 2022-11-02
    Type: Initial release
  • Version 1.1: 2024-01-31
    Changes: Data collection, Refinement description
