7YTX | pdb_00007ytx

Crystal structure of TLR8 in complex with its antagonist


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:
    0.296 (Depositor), 0.294 (DCC)
  • R-Value Work:
    0.220 (Depositor), 0.221 (DCC)
  • R-Value Observed:
    0.224 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7YTX

Ligand Structure Quality Assessment


This is version 1.2 of the entry. See complete history

Literature

A novel Toll-like receptor 7/8-specific antagonist E6742 ameliorates clinically relevant disease parameters in murine models of lupus.

Ishizaka, S.T.Hawkins, L.Chen, Q.Tago, F.Yagi, T.Sakaniwa, K.Zhang, Z.Shimizu, T.Shirato, M.

(2023) Eur J Pharmacol 957: 175962-175962

  • DOI: https://doi.org/10.1016/j.ejphar.2023.175962
  • Primary Citation Related Structures:
    7YTP, 7YTX

  • PubMed Abstract:

    The sensing of self RNA by the endosomal Toll-like receptors (TLRs) 7 and 8 initiates pathogenic mechanisms underlying the autoimmune disease lupus. A blockade of the TLR7/8 signals may, therefore, be a novel therapeutic intervention for lupus. To test the hypothesis, a novel compound E6742 that blocks TLR7/8 activation was identified. The mode of action of E6742 was investigated by analysis of the tertiary structure of TLR7 and 8 in complex with E6742. The in vitro activities of the compound were examined in cellular systems and its therapeutic potential was evaluated in murine lupus models. Tertiary structures of the extracellular domain of TLR7 and 8 in complex with E6742 showed that E6742 binds specifically and non-covalently to the hydrophobic pocket located at the interface of TLR7 or TLR8 homodimers. E6742 potently and selectively inhibited several TLR7/8-mediated cytokine responses in human PBMC. In two mouse models of lupus, oral dosing of E6742 after the onset of disease suppressed increase in autoantibodies and blocked the advance of organ damage. Collectively, the data show that TLR7/8 activation contributes to disease progression and its blocking by E6742 has potential as a therapeutic intervention for lupus.


  • Organizational Affiliation
    • Eisai Inc., Eisai Center for Genetics Guided Dementia Discovery, MA, USA.

Macromolecule Content

  • Total Structure Weight: 195.4 kDa
  • Atom Count: 12,732
  • Modeled Residue Count: 1,499
  • Deposited Residue Count: 1,622
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Toll-like receptor 8
A, B
811Homo sapiensMutation(s): 0
Gene Names: TLR8UNQ249/PRO286
UniProt & NIH Common Fund Data Resources
Find proteins for Q9NR97 (Homo sapiens)
Explore Q9NR97
Go to UniProtKB:  Q9NR97
PHAROS:  Q9NR97
GTEx:  ENSG00000101916
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9NR97
Glycosylation
Glycosylation Sites: 12Go to GlyGen: Q9NR97-1
Sequence Annotations
Expand
Reference Sequence

Oligosaccharides

Help
Entity ID: 2
MoleculeChains Length2D Diagram GlycosylationD Interactions
alpha-D-mannopyranose-(1-3)-alpha-D-mannopyranose-(1-6)-[alpha-D-mannopyranose-(1-3)]beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
C
6N-Glycosylation
Glycosylation Resources
GlyTouCan: G09724ZC
GlyCosmos: G09724ZC
GlyGen: G09724ZC
Entity ID: 3
MoleculeChains Length2D Diagram GlycosylationD Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranoseD,
G [auth H]
2N-Glycosylation
Glycosylation Resources
GlyTouCan: G42666HT
GlyCosmos: G42666HT
GlyGen: G42666HT
Entity ID: 4
MoleculeChains Length2D Diagram GlycosylationD Interactions
alpha-D-mannopyranose-(1-2)-alpha-D-mannopyranose-(1-3)-[alpha-D-mannopyranose-(1-3)-alpha-D-mannopyranose-(1-6)]beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranoseE,
H [auth I]
7N-Glycosylation
Glycosylation Resources
GlyTouCan: G07617FP
GlyCosmos: G07617FP
GlyGen: G07617FP
Entity ID: 5
MoleculeChains Length2D Diagram GlycosylationD Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranoseF [auth G]3N-Glycosylation
Glycosylation Resources
GlyTouCan: G15407YE
GlyCosmos: G15407YE
GlyGen: G15407YE

Small Molecules

Ligands 2 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
JRI
(Subject of Investigation/LOI)

Query on JRI



Download:Ideal Coordinates CCD File
I [auth A],
S [auth B]
(2R,6R)-4-(8-cyanoquinolin-5-yl)-N-[(3S,4R)-4-fluoranylpyrrolidin-3-yl]-6-methyl-morpholine-2-carboxamide
C20 H22 F N5 O2
BLEGXEJTJXNGSC-GMLZMKKNSA-N
NAG

Query on NAG



Download:Ideal Coordinates CCD File
AA [auth B]
BA [auth B]
J [auth A]
K [auth A]
L [auth A]
AA [auth B],
BA [auth B],
J [auth A],
K [auth A],
L [auth A],
M [auth A],
N [auth A],
O [auth A],
P [auth A],
Q [auth A],
R [auth A],
T [auth B],
U [auth B],
V [auth B],
W [auth B],
X [auth B],
Y [auth B],
Z [auth B]
2-acetamido-2-deoxy-beta-D-glucopyranose
C8 H15 N O6
OVRNDRQMDRJTHS-FMDGEEDCSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.90 Å
  • R-Value Free:  0.296 (Depositor), 0.294 (DCC)
  • R-Value Work:  0.220 (Depositor), 0.221 (DCC)
  • R-Value Observed: 0.224 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 145.64α = 90
b = 97.57β = 104.95
c = 143.81γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2023-09-27
    Type: Initial release
  • Version 1.1: 2024-11-20
    Changes: Structure summary
  • Version 1.2: 2026-03-04
    Changes: Refinement description
