7YKE | pdb_00007yke

Crystal structure of chondroitin ABC lyase I in complex with chondroitin disaccharide 4,6-sulfate


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.88 Å
  • R-Value Free:
    0.213 (Depositor), 0.219 (DCC)
  • R-Value Work:
    0.169 (Depositor), 0.180 (DCC)
  • R-Value Observed:
    0.171 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 7YKE

This is version 1.3 of the entry. See complete history

Literature

Biochemical and crystallographic assessments of the effect of 4,6-O-disulfated disaccharide moieties in chondroitin sulfate E on chondroitinase ABC I activity.

Watanabe, I.Miyanaga, A.Hoshi, H.Suzuki, K.Eguchi, T.

(2023) FEBS J 290: 2379-2393

  • DOI: https://doi.org/10.1111/febs.16685
  • Primary Citation Related Structures:
    7YKE

  • PubMed Abstract:

    O-sulfated N-acetyl-d-galactosamine (GalNAc) residues in chondroitin sulfate (CS) play a crucial role in chondroitinase ABC I (cABC-I) activity. CSA containing mainly 4-O-monosulfated GalNAc was a good substrate for the enzyme, but not CSE containing mainly 4,6-O-disulfated GalNAc [GalNAc(4S,6S)]. Each CS isomer exhibits structural heterogeneity; CSE has di-sulfated disaccharide units and mono-sulfated disaccharide units. Disaccharide composition analysis of digested products revealed that mono-sulfated disaccharide units in CSE contributed to the enzyme reactivity. Although enough substrate (CSA) was present in mixtures of CSA and CSE for reaction, the reactivity was reduced depending on the amount of CSE in the mixture. These results suggested that CSE is not only resistant to enzyme digestion but also attenuates enzyme activity. To understand the mechanism of action, crystallography of cABC-I in complex with unsaturated CSE-disaccharide, ΔDi-(4,6)S, was performed. Both 4-O- and 6-O-sulfate groups in ΔDi-(4,6)S interact with Arg500, suggesting that there was a greater interaction between ΔDi-(4,6)S and Arg500 than between mono-sulfated disaccharides and Arg500. Besides, this interaction attenuated enzyme activity by interfering with a function of Arg500, which is the charge neutralization of the carboxy group of D-glucuronic acid (GlcA) residues in CS. When interacting with the CSE-disaccharide unit [GlcAβ1-3GalNAc(4S,6S)] in CS, cABC-I cannot interact with other CS-disaccharide units until it has digested the CSE-disaccharide unit. The low reactivity of cABC-I with CSE is attributable to two suggested factors: (a) resistance of E-units in CSE molecules to digestion by cABC-I, and (b) tendency of E-units in CSE molecules to attenuate cABC-I activity.


  • Organizational Affiliation
    • Medical Affairs, Seikagaku Corporation, Chiyoda-ku, Japan.

Macromolecule Content

  • Total Structure Weight: 116.32 kDa
  • Atom Count: 8,530
  • Modeled Residue Count: 966
  • Deposited Residue Count: 1,021
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Chondroitin sulfate ABC endolyase1,021Proteus vulgarisMutation(s): 0
EC: 4.2.2.20
UniProt
Find proteins for P59807 (Proteus vulgaris)
Explore P59807
Go to UniProtKB:  P59807
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP59807
Sequence Annotations
Expand
Reference Sequence

Oligosaccharides

Help
Entity ID: 2
MoleculeChains Length2D Diagram GlycosylationD Interactions
4-deoxy-alpha-L-threo-hex-4-enopyranuronic acid-(1-3)-2-acetamido-2-deoxy-4,6-di-O-sulfo-beta-D-galactopyranose
B, C
2N/A
Glycosylation Resources
GlyTouCan: G26418LS
GlyCosmos: G26418LS

Small Molecules

Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
MG

Query on MG



Download:Ideal Coordinates CCD File
D [auth A]MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.88 Å
  • R-Value Free:  0.213 (Depositor), 0.219 (DCC)
  • R-Value Work:  0.169 (Depositor), 0.180 (DCC)
  • R-Value Observed: 0.171 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 49.069α = 90
b = 94.497β = 90
c = 229.356γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
PDB_EXTRACTdata extraction
XDSdata reduction
Aimlessdata scaling
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2022-11-30
    Type: Initial release
  • Version 1.1: 2022-12-28
    Changes: Database references
  • Version 1.2: 2023-05-17
    Changes: Database references
  • Version 1.3: 2023-11-29
    Changes: Data collection, Refinement description
