7YFV

Structure of Rpgrip1l CC1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.263
  • R-Value Work: 0.214
  • R-Value Observed: 0.216

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Structure of the N-terminal coiled-coil domains of the ciliary protein Rpgrip1l.

He, R.Chen, G.Li, Z.Li, J.

(2023) iScience 26: 106249-106249

  • DOI: https://doi.org/10.1016/j.isci.2023.106249
  • Primary Citation of Related Structures:
    7YFU, 7YFV

  • PubMed Abstract:

    Rpgrip1l is one of the key ciliary proteins located at the transition zone of the primary cilium, an important organelle for cells to sense the outer environment. Mutations in the RPGRIP1L gene are associated with various ciliopathies. Here, we focused on the N-terminal coiled-coil of Rpgrip1l. By comprehensive biochemical and structural characterizations, we demonstrated that the two predicted coiled-coil regions (CC12) located at Rpgrip1l N-terminus each can form a stable parallel dimer. We further showed that overexpression of Rpgrip1l CC12 in NIH/3T3 cells significantly shortened the length of primary cilia, and this effect depended on the dimer formation. In addition, we found that CC12 of the homolog protein Rpgrip1 in mouse and human were significantly different from Rpgrip1l. Finally, we confirmed that some disease-related mutations can alter the dimeric states of CC12 of Rpgrip1l or Rpgrip1, which might explain the pathogenic mechanisms.


  • Organizational Affiliation

    Division of Cell, Developmental and Integrative Biology, School of Medicine, South China University of Technology, Guangzhou 510006, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Protein fantom
A, B, C, D
60Mus musculusMutation(s): 0
Gene Names: Rpgrip1lFtmNphp8
UniProt & NIH Common Fund Data Resources
Find proteins for Q8CG73 (Mus musculus)
Explore Q8CG73
Go to UniProtKB:  Q8CG73
IMPC:  MGI:1920563
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8CG73
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free: 0.263
  • R-Value Work: 0.214
  • R-Value Observed: 0.216
  • Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 35.167α = 90
b = 104.674β = 105.08
c = 38.413γ = 90
Software Package:
Software NamePurpose
DENZOdata reduction
SCALEPACKdata scaling
PHENIXrefinement
PDB_EXTRACTdata extraction
Arcimboldophasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China--

Revision History  (Full details and data files)

  • Version 1.0: 2023-05-17
    Type: Initial release
